Wren TOWER UNIT Assembly Manual

300 and 600 2 door 6 shelf. 2070 x 300, 2070 x 600, 2250 x 300 tall, 2250 x 600 tall.
Hide thumbs Also See for TOWER UNIT:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual See also: Assembly Manual
TOWER UNIT
300 600 2 Door 6 Shelf
Assembly Guide
2070 x 300
2070 x 600
2250 x 600
2250 x 300
Tall
Tall
For Internal Use: FI.WR.INS.040_WKIN00140_Tower_300-600_2Dr6Shelf_Rev2.indd

Advertisement

loading
Need help?

Need help?

Do you have a question about the TOWER UNIT and is the answer not in the manual?

Questions and answers

Related Manuals for Wren TOWER UNIT

Summary of Contents for Wren TOWER UNIT

  • Page 1 TOWER UNIT 300 600 2 Door 6 Shelf Assembly Guide 2070 x 300 2070 x 600 2250 x 600 2250 x 300 Tall Tall For Internal Use: FI.WR.INS.040_WKIN00140_Tower_300-600_2Dr6Shelf_Rev2.indd...
  • Page 2 TOWER UNIT 300 600 2 Door 6 Shelf BEFORE YOU START INSTALLATION Assembly Guide SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel B Panel C Panel E Shelf Legs...
  • Page 3 TOWER UNIT 300 600 2 Door 6 Shelf Step 1. Seat dowel (F) into holes in Assembly Guide both end panels (B) as shown. Step 2. Seat cam dowel (G) into holes in both end panels (B) Seat (G) as shown.
  • Page 4 TOWER UNIT 300 600 2 Door 6 Shelf Assembly Guide Step 5. Slide back panel (A) into groove of end panels (B). Once back panel (A) is in position, ensure the panel is flush & square with bottom of end panels (B).
  • Page 5 TOWER UNIT Step 8. 300 600 2 Door 6 Shelf Secure each of the legs into place with 2 x 15mm screws (L) per leg Assembly Guide Leg position diagram Front Ensure legs are rotated as shown so that part of it is supporting the end panels (B).
  • Page 6 TOWER UNIT 300 600 2 Door 6 Shelf Assembly Guide 2006 1974 1826 1794 Step 11. Hinge mounting plate attach hinge plates onto end panels (B) In locations shown using 8 x 15mm screws (L) Hinge side to be mounted in accordance to customer kitchen plan.
  • Page 7 TOWER UNIT See Customer Specific Kitchen Plan For Tower Frontals 300 600 2 Door 6 Shelf Step 12. Assembly Guide Insert hinge where required in holes as shown. Hinges Step 13 Secure hinges by tightening 2 screws with hinge dowels attached. These are already positioned within the hinges.
