Zaxcom QRX200
Antenna being used
Indicates the signal is being received by antenna 1 (left antenna connector)
Indicates the signal is being received by antenna 2 (right antenna connector)
RF signal strength
This shows the radio signal strength of the corresponding TRX transmitter. The RF signal is depicted as a
staircase pattern with the lowest step (low signal strength) on the left and building up as it progresses to the
right (higher signal strength). When more stairs are showing the stronger the signal is.
8
Home Screen
