INSTALLATION INSTRUCTIONS FOR PART 99-8219
Toyota FJ Cruiser 2007-up
KIT FEATURES
• DIN radio provision with pocket
• ISO radio provision with pocket
KIT COMPONENTS
• A) Radio Housing • B) Housing Brackets • C) ISO Snap In Brackets • D) Trim Plate
A
WIRING & ANTENNA CONNECTIONS (Sold Separately)
Wiring Harness:
• 70-1761 Toyota harness 1987-up
Antenna Adapter:
• Not Required
APPLICATIONS
99-8219
B
TOOLS REQUIRED
Panel Removal Tool • Phillips Screwdriver
METRA. THE WORLD'S BEST KITS.™
1-800-221-0932
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
C
metraonline.com
D
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metra Electronics 99-8219
Summary of Contents for Metra Electronics 99-8219
- Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-8219 APPLICATIONS Toyota FJ Cruiser 2007-up 99-8219 KIT FEATURES • DIN radio provision with pocket • ISO radio provision with pocket KIT COMPONENTS • A) Radio Housing • B) Housing Brackets • C) ISO Snap In Brackets • D) Trim Plate WIRING &...
- Page 2 99-8219 Table of Contents Dash Disassembly – Toyota FJ Cruiser 2007-up Kit Assembly – DIN radio provision with pocket – ISO radio provision with pocket Caution Metra recommends disconnecting the negative battery terminal before beginning any installation. All accessories, switches, and especially air bag indicator lights must be plugged in before reconnecting the battery or cycling the ignition.
- Page 3 99-8219 Dash Disassembly 1. Remove two Phillips screws from bottom part of side trim panels. Figure A) 2. Using a panel removal tool, carefully remove the side trim panels. (Figure B) 3. Remove (2) Phillips screws from radio trim panel. (Figure C) 4.
-
Page 4: Din Radio Provision With Pocket
Kit Assembly 99-8219 DIN radio provision with pocket 1. Locate the factory wiring harness in the dash. Metra recommends using the proper mating adapter from Metra or AXXESS. Re-connect the negative battery terminal and test the unit for proper operation. - Page 5 Kit Assembly 99-8219 ISO radio provision with pocket 1. Locate the factory wiring harness in the dash. Metra recommends using the proper mating adapter from Metra or AXXESS. Re-connect the negative battery terminal and test the unit for proper operation.
