Zennio MAXinBOX FC 0-10V VALVE User Manual page 35

mode while the valve is open. This ensures that the fan remains in motion
whenever the valve stays open.
Delays. Please refer to section 2.5.3.1.
Silent mode. Please refer to section 2.5.3.2.
Custom Start. Please refer to section 2.5.3.3.
ETS PARAMETERISATION
The Fan screen (see Figure 14) is accessible by default after enabling the Fan Coil
module. It contains the following parameters:
SPEED STATUS OBJECTS
Individual Speed Objects (1 Bit): enables/disables the "[FCV1] Fan: Speed
x (Status)" binary objects, where "x" runs from 0 to 4 (or to the number of fan
speed; see section 2.5.1). These objects show the value "1" when the speed
level they refer to is active and "0" when not.
Enumeration Object (1 Byte): enables/disables the "[FCV1] Fan:
Enumation Speed (Status)" one-byte object, which will show values from 0
to 4 according to the current fan speed.
Percentage Object (1 Byte): enables/disables the "[FCV1] Fan: Percentage
Speed (Status)" one-byte object, which will show values from 0% to 100%
according to the current fan speed and to the KNX standard.
http://www.zennio.com
Available speeds
One speed
Two speeds
Three speeds
Table 4. Manual control through the percentage object
Speed Percentage
0
1 1% – 100%
0
1 0.4% – 50.2%
2 50.4% – 100%
0
1 0.4% – 33.3%
2 33.7% – 66.6%
3 67% - 100%
Technical Support: http://zennioenglish.zendesk.com
MAXinBOX FC 0-10V VALVE
0%
0%
0%
35
