2.5.1.4 SCENES

It is possible to define up to five scenes so that, when the corresponding value is
received from the bus, the module adopts a certain state, which must be defined in
terms of the following options:
On / Off state of the module.
Activation / deactivation of the Ventilation mode.
Manual / Auto mode for the fan speed selection.
Fan speed (in case the above option is set to manual).
Activation / deactivation of the silent mode.
It is important to bear in mind that executing a scene is equivalent to sending the
analogous orders to the corresponding objects. Therefore, the result will depend
on the initial state of the fan coil module when the scene is executed.
For example, if a manual speed selection order is received during the valve purge
process, the order will be buffered and executed after the completion of the purge, as it
would happen in case of receiving the request through the analogous communication
object.
On the other hand, if the scene in execution implies turning the fan coil module off, the
response will be immediate, and the purge process will be aborted.
This module does not permit scene recording.
ETS PARAMETERISATION
Once Scenes has been enabled from the Configuration tab (see section 2.5.1), a new
tab named "Scenes" will be available in the tab tree on the left, containing the following
options:
