SIP User's Manual
From the 'Protocol Type' drop-down list, select the required protocol.
4.
Notes:
Modify the relevant trunk configuration parameters according to your requirements.
5.
To configure the different behavior bits: either enter the exact hexadecimal value of
6.
the bits in the field to the right of the relevant behavior parameter, or directly configure
each bit field by completing the following steps:
Click the arrow button (-->) to the right of the relevant behavior parameter; a new
a.
window appears.
Modify each bit field according to your requirements.
b.
Click the Submit button to save your changes.
c.
After modifying the parameters:
7.
•
To apply the changes to the selected trunk only, click the Apply Trunk Settings
button.
•
To apply the changes to all the trunks, click the Apply to all Trunks button.
The screen is refreshed; parameters become read-only (indicated by being grayed).
8.
The Stop Trunk button replaces the Apply Trunk Settings button.
To save the changes to flash memory, refer to 'Saving Configuration' on page 256.
9.
Note:
To reset the gateway, refer to 'Resetting the Gateway' on page 257.
10.
Version 5.2
•
Different trunks can be defined with different protocols (CAS or ISDN
variants) on the same gateway (subject to the constraints in the
gateway's Release Notes).
•
When modifying the 'Protocol Type' field, the menu is automatically
updated according to the selected protocol (ISDN, CAS, or Transparent).
Additional parameters are appropriate to the selected protocol type.
Some parameter configuration options require device reset; when this is the
case, the Embedded Web Server prompts the user.
181
5. Web-based Management
September 2007
