BEACH FRONT
WOODEN PLAY SET
MO DEL: 1605022
• Owner's Manual
• Frequently Asked Questions
• Assembly Instructions
• Warranty Information
Features the
fastening system.
Save this assembly manual for future reference in the event that
you need to order replacement parts.
Made in China
