4
Hardware Installation
4.1
Tools Needed
To install the NetGuardian, you'll need the following tools:
Phillips No. 2 Screwdriver
4.2
Mounting
The NetGuardian 216 can be mounted in a 19" rack or a 23" rack by using the provided rack ear for each size.
Two rack ear locations are provided, the unit can be mounted either on the right or left. Attach the appropriate
rack ear in the flush-mount or rear-mount locations shown in Figure 4.1.
Note: Rack ears can be rotated 90° for wall mounting or 180º for other mounting options not shown.
Computer with T/NG216-Dialup loaded
Fig. 4.1. The NetGuardian 216 can be flush or rear-mounted
Small Standard No. 2 Screwdriver
5
