18
4. In Communication Mode, select TCP/IP — see Figure 5.6.
5. Enter the NetGuardian IP Address.
6. Press Set.
7. Proceed with configuration.
Note: The IP port is set to 2002 by default.
The NetGuardian's default IP address is 192.168.1.100 and a default subnet mask of 255.255.0.0. See section
4.6.1 (Preliminary Network Connection) to configure the NetGuardian to be in the same subnet as your computer
or network using only a TCP connection.
5.3

T/NG216-Dialup Help

Comprehensive help is always available while using T/NG216-Dialup. To view the on-screen help files, select
T/Config Help from the Help menu (see Figure 5.7) or press F1.
5.4

Editor Toolbar

Open
Save As
New Save
Click on the icon shortcuts to open a saved configuration file, save your settings to a file, delete a saved file, write
to changes to the NetGuardian, read from the NetGuardian, or exit Editor Mode.
Fig. 5.6. Connect via TCP/IP
Fig. 5.7. Select T/NG216-Dialup Help for comprehensive help
Delete
NetGuardian 216
Write to
NetGuardian 216
Fig. 5.8. Editor Toolbar Options
Read from
Exit session
