Power Led - ETC Response Setup Manual

ETC Setup Guide
Four-Port DIN Rail Mounted Gateway
Hold button 5 sec to
Hold button 5 sec to
Hold button 5 sec to
Status and Feedback LEDs
Once properly connected to the network, the LEDs will provide the following feedback.

Power LED

• A constant blue LED indicates power to the gateway
Network LED
• A constant green LED indicates a valid network connection is present.
• The LED will flicker with network traffic.
Configuration and Termination
After the gateway has been securely mounted, each individual port can be assigned using Net3 Concert
software to function as either DMX input or DMX output.
Above each DMX port header is a termination switch. The termination switch must be set according to the
configuration of the port and the position in the DMX chain.
• If the port is configured to be an output, the switch should be set to "OUTPUT." This is the default.
• If the port is configured to be an input, AND is at the end of the DMX chain, the switch should be set
to "INPUT."
• If the port is configured to be an input, and is NOT at the end of the DMX chain, the switch should
be set to "OFF."
Note:
Four-Port DIN Rail Mounted Gateway Setup Guide
ACN Gateway Version
• Displays the version number of the software currently running on this device.
7.0.0.9.0.X
• The IP mode is set to Static, "Switch to Dynamic IP" displays. If the IP mode is
Reset Dynamic IP
Dynamic, "Reset Dynamic IP" displays. Resetting the Dynamic IP erases the current
IP from memory and requests an IP from the DHCP address service after reboot.
• Software is retrieved from the current TFTP update server.
Download Software
• Restoring defaults will cause the gateway to reset ALL settings to the factory
Restore Defaults
defaults.
Mac Address
00:C0:16:00:00:1A
For gateways running software updated to v7.0.0 or later, you can set the fourth port for
serial output by setting the alternate serial termination switch to RS232-C. The serial
output is configured using the NET3 Concert application.
Page 5 of 5 ETC
