CHAPTER -1: EXPLANATION OF PRODUCT
11
10
9
=
8
1. Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Filters
6. Rating plate
Turbo Drying Unit:
This system provides better drying
performance for your dishes.
12
EN-4
7. Control Panel
8. Detergent and rinse-
aid dispenser
9. Salt dispenser
10. Upper basket track latch
11. Upper Cutlery Basket
Ceiling Spray Arm:
It provides better washing for
the dishes in the upper basket.
1
2
3
4
5
6
7
13
