CHAPTER -7: SWITCHING ON THE MACHINE AND SELECTING A
PROGRAMME
Note: When a program that is incompatible with the Extra silent & fast option is selected,
when the button is pressed a buzzer sound is heard which indicates that the selected option is not available.
7.) Tablet Detergent Touch Button ( 3 in 1 button )
Press the Tablet detergent touch button when you use combined detergents that include salt and rinse aid.
8.) Salt Warning Indicator
To determine whether there is sufficient softening salt in the machine, check to see if the Salt
warning light on the display is lit. When Salt warning light starts coming on, add salt to the salt compartment.
Rinse aid Warning Indicator
To determine if there is sufficient rinse aid in the machine check the rinse aid warning light on the
display. When the rinse aid warning light starts coming on, add rinse aid to the rinse aid compartment.
End of Program
The machine makes a buzzer sound 5 times when the program is completed. When the door is
opened after the selected washing program is completed, the buzzer activation will end and a '0'
character is showed on display.
Note: Each time the machine is switched on, the Eco program and Energy save option are set to as default and
previously chosen options are cancelled. When selecting programs other than Eco, the Energy save icon will go
out.

Operating your machine

1
Switching on the machine
1- Touch the power On/Off key.
When the machine is powered on,when the On/Off touch button (1) is pressed, two dashes appear in the
program display.
2- When selecting a program with the program touch button (2), the program selected ( P1,P2,etc ) appears on
the program display , from (P1 to P8) and the duration of the program are displayed alternately for 3 sec. for the
program and then 1 sec. for the duration time.
3- "If desired, you can choose additional functions. (4-7)
4- Close door.The program starts automatically.
Note:If you decide not to start to machine after selecting the program, press the on/off touch button (1). The
machine will be ready for the new program selection when you press on/off touch button (1) again. Select the
new program by pressing the program touch button (2).
Program follow-up
- When the door is opened after the selected washing program is completed, the buzzer activation will end and
a '0' character is showed on display (3).
- If the door is opened during washing cycle, the remaining time of the selected program is shown on the display
(3).
- The machine makes a buzzer sound 5 times when the program is completed.
Changing a program
To change the program while a wash program is going.
1- Open the door and select a new program by pressing the Program touch button (2).
2- After closing the door, the newly selected new program start from the point where the original program
reached, but with the new parameters (temperature, cycles) of the new program.
Note: When opening the door of the machine in order to stop the washing program before it has completed, first
carefully open the door slightly in order to avoid water spillage
Cancelling and resetting a program
To cancel a program currently in progress or in a standby position.
1- Open the door of the machine. The last selected program will appear on the display (3).
2- Press and hold the program touch button (2) for 3 seconds. The display (3) will count from ''3 to 1'' and then
show ''0:01" to indicate that cancelling is ready.
8
2
3
4 5 6
7
EN-21
