4. Main Unit and Camera Descriptions
4.1 Main Unit Description
1. Power button
2. Video Record button with sub‐functions
3. Snapshot (photo) Image button
4. Power adaptor jack
5. Audio headset jack (for voice‐overs)
6. AV Output jack (PAL or NTSC)
7. SD Card slot
8. Keyed Camera signal jack
9. Monitor display
10. USB jack
11. Function buttons (seen next section)
12. Camera LED work lamps intensity adjust
Note: Reset button & mounting hole on back of unit.
4.2 Camera Description
1. LED work lamps (4)
2. Camera with macro lens
3. Mounting screw connects to back of main unit
4. Camera position lock mechanism
5. Articulating (240
camera lens
6. Camera signal cable connects to top of main unit
o
) control remotely points the
8
9
10
11
12
5
EXTECH INSTRUMENTS
1
3
2
4
5
6
HDV540‐en‐US_V1.0 12/15
