11. Specifications
HD VideoScope monitor
Camera assembly
Display
Camera Connector
Recording medium
Image (photo) storage format
Image zoom
Storage capacity
Interface
Video file formats
Video output formats
Frame rate
Compression format
Video file size
Camera Zoom
Camera resolution
Camera cable length
Camera Outer diameter O.D.
Camera focal distance
Camera bend radius
Camera housing
Camera Field of View (FOV)
Camera work lamps
Camera work lamp output
Total weight of main unit
Dimensions of main unit
Operating temperature
Storage temperature
Battery
Power adapter
Battery life and charge time
Power consumption
IP Rating
HDV500
Model: HDV5‐6CAM‐1AFM
3.5 in. (8.9cm) TFT monitor 320 x 240 pixels (HDV500)
M12 (5 pin)
SD Card 2~32GB, SDHC compatible (32G max. Class‐10); 4GB supplied
JPEG (640 x 480)
10x in photo image view mode
Up to 20,000 images or 6 hours of video on 4GB SD Card
Mini USB 2.0
AV (audio‐visual) output to external monitor
MPEG4 / AVI
NTSC & PAL
30 fps (frames per second)
MPEG4/CVBS
120 min. = 1.4 GB
4x
640 x 480 pixels
3.3' (1m)
0.24" (6mm)
0.79 to 2.36" (2 to 6cm)
o
240 articulation
Stainless Steel
o
60
Four (LED) lamps with intensity control (dial on left of main unit)
3500 Lux @ 20mm (max.)
14.1 oz. (400g) with battery
8.3 x 4.3 x 1.6 in. (21 x 11 x 4cm)
o
Main unit: 32~122 F (0~50
o
Main unit: 32~122 F (0~50
Rechargeable Li‐Polymer battery 3.7 (V); not user‐serviceable
Universal AC Adaptor VAC 100~240V, 50~60Hz, 0.3A Max.
DC 5V, 2.5A, 12.5W
4 hour battery life; Charging time 5 hours @ 77
340mA / 5 V
IP67 (compact, high resolution water‐proof camera probe)
13
EXTECH INSTRUMENTS
o o
C); Camera: ‐4~158 F (‐20~70
o o
C); Camera: ‐4~158 F (‐20~70
o
F (25
HDV540‐en‐US_V1.0 12/15
o
C)
o
C)
o
C)
