Extech Instruments HDV540 User Manual page 2

Table of Contents
1. INTRODUCTION
1.1 Models and Descriptions
1.2 Features
2. SAFETY
3. QUICK START
4. MAIN UNIT AND CAMERA DESCRIPTIONS
4.1 Main Unit Description
4.2 Camera Description
5. BUTTON DESCRIPTIONS
6. COMMON DISPLAY ICONS
7. RECHARGEABLE BATTERY AND AC POWER ADAPTOR
7.1 Rechargeable Battery
7.2 Universal AC Power Adaptor
8. OPERATION
8.1 Connecting and Powering the System
8.2 Main Display
8.3 Camera Articulation Control
8.4 Magnification (Zoom)
8.5 Video Recording, Viewing, and Deleting
8.6 Audio Voice‐Over with Video Recording
8.7 Image Capturing, Viewing, and Deleting
8.8 LED Work Lamp Intensity Control
8.9 System Reset Button
8.10 AV Connection to External Monitor
8.11 USB Connection for PC File Transfer and Battery Charging
9. FUNCTION PROGRAMMING MENU
9.1 Storage Devices (SD Cards and USB Flash Devices)
9.2 Set DATE/TIME and AUTO POWER OFF Time
9.3 AV Output Selections
9.4 Factory Default Reset and Firmware Version
9.5 Image and Video Files
10. MAINTENANCE
10.1 Cleaning
10.2 Battery Replacement
11. SPECIFICATIONS
12. WARRANTY
2
EXTECH INSTRUMENTS
HDV540‐en‐US_V1.0 12/15
