The Channel Screen - Codan 2110 Getting Started Manual

The front panel

The channel screen

Rx/Tx indicator
channel name
Tx freq (kHz)
(not shown if Tx/Rx
are the same)
internal speaker
icon (shown when
speaker enabled)
28
The channel screen is displayed when you press
Figure 4: The channel screen in the Channel List
signal
strength
indicator
Tx power
indicator
(Hi/Lo)
antenna
selection icon
(internal
50 ohm )
When the transceiver is scanning, the call type icon is replaced
by the scanning icon
replaced by Scanning.
mute type
indicator
(V/S,
highlighted
when mute
is on)
call
type
icon
mode
soft function keys
and the channel information is
2110 SSB Transceiver Getting Started Guide
or VIEW.
Rx freq (kHz)
battery status
indicator
