KTM 400-660 LC4 1998-2005 Repair Manual page 30

2-15E
FIG. PART NO.
1 560.12.001.000
2 583.29.003.000
3 580.12.005.025
4 584.29.009.000
4# 580.12.009.000
5 510.12.016.000
5# 584.29.031.000
6 580.12.015.089
580.12.015.095
580.12.015.100
580.12.015.101
585.29.015.102
7 590.29.021.044
8 590.29.019.000
9 590.29.033.000
10 590.29.041.000
11 6.899.785
12 584.29.059.000
14 590.29.034.000
15 151.12.017.000
16 151.12.018.000
16 151.12.018.100
17 584.29.012.000
18 3090.98
19 584.29.037.040
19 584.29.037.043
20 580.30.080.000
22 510.12.012.000
23 546.29.027.000
26 580.29.026.007
39 583.29.039.000
48 584.29.048.000
49 503.29.050.000
SPECIAL TOOLS MOTOR
DESCRIPTION
Universal engine work stand
Clutch holder
Mounting sleeve for crankshaft seal ring Ø 25 mm
Magneto extractor (Kokusan)
Magneto extractor (SEM)
Protection cover for crankshaft (SEM)
Protection cover for crankshaft (Kokusan)
Piston ringspanner Ø 89 mm
Piston ringspanner Ø 95 mm
Piston ringspanner Ø 100 mm
Piston ringspanner Ø 101 mm
Piston ringspanner Ø 102 mm
Extractor for primary gear and clutch hub
Valve mounting set
Extractor
Feeler gauge for valve clearance
Loctite 243 blue 6 ml
Loctite 648 red 20 ml
Wrench for mixture regulating screw
Gear puller
Internal bearing puller 12 - 16 mm
Internal bearing puller 18 - 23 mm
Flywheel holding spanner (Kokusan)
Seal (Three-Bond)
Mounting tool inner ring NJ207 (all versions of LC4)
Mounting tool inner ring NJ306 (LC4-E)
Crankshaft locking bolt
Chain sprocket holder
Clutch rivetting tool
Limit plug gauge Ø 7,05 mm
Oil filter wrench
Syringe for pipe oil
Bleeding syringe for hydraulic clutch
