ELECTRICAL – LC4 COMPETITION
bl
ge

Charging system

1
2
3
4
5

Leakage inspection

The drop test must be performed before checking the voltage
regulator/rectifier
– Turn off the ignition and disconnect the ground wire from the
– Insert an amperemeter between the ground wire and the negative
– Check for power consumers, should the measured value exceed the
● defective voltage regulator-rectifier
● leak currents in the socket connectors, in the ignition lock or in the
2
Generator
Regulator-rectifier
Main fuse (20 A)
Battery (12V / 8 Ah)
Capacitor
battery.
pole of the battery.
Setpoint value: max. 1 mA
indicated maximum value.
Example:
starter relay.
ignition
ge-r
lock
3
5
4
br
