If you have several products communicating with a MIDI connection, you can use the "MIDI
OUT/THRU" output of the Torpedo Studio, which mirrors every MIDI message coming in through the
"MIDI IN" input.
6.1 Program Change (PC)
Every preset in the Torpedo Studio is identified by a corresponding program number. Preset 1 of the
Torpedo Studio corresponds to the MIDI PC 1. You can address the 100 presets (from 1 to 100, le PC
100 appelant le preset 00). So you can access every preset by sending a Program Change message
with the appropriate number.
6.2 Control Change (CC)
The following table indicates the Control Change numbers for every parameter, as well as their range
and behavior.
Parameter
Simulation bypass
Power Amp
On/Off
Model
Volume
Presence
Depth
Character
Miking
Mode
Speaker
User
Mic
Distance
Center
Position
Variphi
Overload
Dry/Wet
Post-FX
Post-FX bypass
EQ
Low Gain
Low Freq
Mode
User's manuals - http://wiki.two-notes.com/
45/52
CC#
Range
Ch A Ch B
Simulation mode
0 0-1 0 = Off(Bypass) ; 1 = On
1 64 0-1 0 = Off ; 1 = On
2 65 0-7 0 = Model #0 ; 1 = Model #1...
3 66 0-30 0 = 0dB ; 30 = 30dB
4 67 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
5 68 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
6 69 0-1 0 = Triode : 1 = Pentode
7 70 0-3 0 = Off ; 1 = Cab ; 2 = User (Ch B : 3 = Link)
8 71 0-x 0 = Cab #0 ; 1 = Cab #1...
9 72 0-x 0 = File #0 ; 1 = File #1...
10 73 0-7 0 = Mic #1 ; 1 = Mic #1...
11 74 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
12 75 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
13 76 0-1 0 = Back : 1 = Front
14 77 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
15 78 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
16 79 0-127 0 = 0% ; 63 = 50% ; 127 = 100%
17 0-1 0 = Off(Bypass) ; 1 = On
18 81 0-40 0 = -20dB ; 20 = 0dB ; 40 = 20dB
19 82 0-127 Specifi mapping to Hz
20 83 0-3 0 = Off ; 1 = Guitar : 2 = Bass ; 4 = Link (Ch B : 3 = Link)
