When powering-on the Torpedo Studio, you will hear the sound of a relay (a
brief click). This corresponds to the activation of the loadbox of the Torpedo
Studio, which allows your amplifier to run without a speaker cabinet. It is
important to always power on the Torpedo Studio before powering on your
amplifier.
The Torpedo Studio starts on preset 0. Now the input gain and output volume must be set up.
1. Turn up the volume of your amplifier to the level you want and play for a few seconds: turn the
input gain (number 2 in figure "3.1.1 Front panel") until the signal stays in the top green/yellow
area on the input bargraph.
2. Turn the output volume gain (number 7 in figure "3.1.1 Front panel") until the signal stays in
the top green/yellow area on the output bargraph.
3. Adjust the Headphones output volume to your taste.
You can now browse the presets with the NAVI knob (number 6 in figure "3.1.1 Front panel"). Use the
knob to change the preset number and press OK to load the preset.
For more flexibility, the values of the output volume is stored within each preset. Therefore, you may
have to adjust those parameters depending on the presets.
Within a few minutes, you have prepared your system for silent performance with headphones, but
also for stage sound pick-up (through the analog outputs) or for digital studio recording (through the
AES/EBU or S/PDIF outputs).
We will expand upon the numerous creative options and convenient features offered by the Torpedo
Studio further down in this manual.
4.2 Routing the Inputs/Outputs
The Torpedo Studio is a dual channel processor accepting mono or stereo input signals that can be
treated as independent or linked. The following illustration presents the various elements and how
they are configured.
Inputs are illustrated by Amp or L for the left input (Line Left, AES/EBU Left or S/PDIF Left) and
R for the right input (Line Right, AES/EBU Right or S/PDIF Right), depending on the selected
Input Mode in the Setup menu.
The simulation channels are illustrated by A and B
Outputs are illustrated by L and R. All the outputs (Line, AES/EBU, S/PDIF and headphones) get
the same left and right signals.
