  • Page 1 Spray Height Controller Hagie 2005 STS Installation Manual Improving the competitiveness of Industry and Agriculture through Precision Measurement...
  • Page 2 Reorder P/N: UC4+BC+HG3-INST Rev F (Hagie 2005 STS) NOTICE NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information contained...
  • Page 3 TABLE OF CONTENTS INTRODUCTION ..........................1 GENERAL SYSTEM DESCRIPTION ....................2 PARTS LISTS ............................3 INSTALLATION PROCEDURE ......................8 ......................8 ENSOR NSTALLATION ....................11 ENSOR NSTALLATION ....................... 12 ENSOR NSTALLATION 4.3.1 Boom Roll Sensor Mounting....................13 4.3.2 Chassis Roll Sensor Mounting ....................14 4.3.3 Temperature probe........................

  • Page 4: Introduction

    INTRODUCTION Congratulations on your purchase of the NORAC UC4+ Spray Height Controller. This system is manufactured with top quality components and is engineered using the latest technology to provide operating features and reliability unmatched for years to come. When properly used the system can provide protection from sprayer boom damage, improve sprayer efficiency, and ensure chemicals are applied correctly.

  • Page 5: General System Description

    Any installation procedure complete installation. However, NORAC requiring boom movement will need to be cannot guarantee all parts fit as intended due done first. Once the hydraulics have been to the variations of the sprayer by the...
  • Page 6 UC4 PLUS ROLL SENSOR W TEMPERATURE PROBE 44642 UC4 PLUS ROLL SENSOR 44865-15 HYDRAULICS FITTING KIT - HG3 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL UC4+BC+HG3-INST MANUAL INSTALLATION UC4+ HAGIE 2006 STS 44963D VALVE BLOCK ASSEMBLY 2 STATION CC/LS PROP DT 4 BOLT...
  • Page 7 Substitution parts will in no way affect the operation of the system provided that they are installed as directed. Item V01 – 2 Station Valve Block (44963D) may be substituted with: Item Part Number Name Quantity 44933D VALVE BLOCK ASSEM UC4-BC 2-STATION CC/LS VARIABLE RATE The 44933D is a direct replacement for the 44963D.
  • Page 8 FACE P - PIPE The use of dielectric grease is not recommended on any NORAC electrical connections. To ensure all stainless steel hardware does not gall or seize apply a light coating of the supplied Permatex Anti-seize grease to all threaded parts upon installation. Permatex Anti-seize lubricant is...
  • Page 9 The parts that come with your UC4+ Spray Height Control system are shown below in their general installation configuration. Figure 2 – UC4+ Spray Height Control Components...
  • Page 10 Figure 3 – Hydraulic Plumbing Schematic...

  • Page 11: Installation Procedure

    (M01) Operator’s Manual implications. a) Assemble the bolt and nut into the collar. 4. Mount the NORAC UC4+ ultrasonic b) Grease the bottom edge of the collar sensor (E02) into the sensor brackets. and the angled tube of the base.
  • Page 12 The sensors should be oriented forward General mounting rules for UC4+ (ahead) of the boom (see Figure 6 and ultrasonic wing sensors: Figure 8). a) In its lowest position, the sensor mouth must be 9 inches or more When installing the UC4+ sensors from the ground.
  • Page 13 3 SENSOR SYSTEM 5 SENSOR SYSTEM Figure 9 – Sensor Serial Number Installation Location...
  • Page 14 4.2 M ENSOR NSTALLATION 1. Assemble the main lift sensor bracket General mounting rules for ultrasonic (B11) as shown in Figure 10. main lift sensor: a) Mount the sensor at the midpoint of Sensor Mounting the main lift section. Collar b) The sensor must have a 12-inch Bracket Tube diameter clear view of the ground...
  • Page 15 4.3 R When mounting the roll sensors use the ENSOR NSTALLATION following guidelines and refer to Figure 14. To mount the roll sensors, the roll sensor brackets will have to be bent. The brackets 1. Ensure the roll sensors are sitting relatively level when the sprayer chassis are supplied with a 90°...
  • Page 16 Chassis Roll Sensor Boom Frame Roll Sensor Figure 14 – Mounting Guidelines The roll sensors must be mounted with the Amp connectors pointing to the right. Figure 15 – Roll Sensor Mounting with Respect to Sprayer Orientation 4.3.1 Boom Roll Sensor Mounting 3.

  • Page 17: Chassis Roll Sensor Mounting

    4.3.2 Chassis Roll Sensor Mounting The chassis roll sensor must be attached to 2. Cable-tie the bracket to a square edge the chassis of the sprayer. To mount the (square tube). chassis roll sensor, refer to the following 3. The AMP (circular) connector must exit guidelines.

  • Page 18: Valve Mounting

    When changing the boom hydraulic hoses leave the booms in TRANSPORT POSITION. 44933D IMPORTANT: Figure 18 – NORAC Valve Block Component failure 2. Install the orifices (F08) into the "A" contamination is not covered under the ports with the notch facing inward as UC4+ Spray Height Control system shown in Figure 19.

  • Page 19: Hydraulic Plumbing

    44933D Hagie “raise” lines. Figure 19 – Valve Block Assembly 5. Mount the NORAC valve (V01) to the Ensure there are no other orifices left side of the sprayer, on the center present between the NORAC valve rack, using the supplied bolts (Figure block and the boom cylinders.
  • Page 20 4.5 E LECTRICAL NSTALLATION Depending on the valve block part 1. Install the UC4+ Control Panel (E01) in number, “UP” “DOWN” the cab of the sprayer. Mount the panel connectors will be on opposite sides of the where it will be clearly visible and block.

  • Page 21: 4.6 C Ompleting The

    6. Cable-tie installed cables every 12 manual to check for proper installation. inches. If you still have trouble, contact NORAC for assistance. IMPORTANT: 3. Turn on the power for the UC4+ Control Panel using the switch on the side of its Provide enough slack in all cables to chassis.

  • Page 22: Electrical Reference – Cable Drawings

    ELECTRICAL REFERENCE – CABLE DRAWINGS 5.1 I C03: 44656D – V ALVE ABLE ARIABLE 5.2 I C04: 44664 – C UC4 CAN N ABLE...
  • Page 23 5.3 I C05: 44687 – C UC3 S ABLE ENSOR...
