DigitaLinx DL-UHDILC Quick Install Manual

Hide thumbs Also See for DL-UHDILC:

Advertisement

Quick Links

DL-UHDILC Quick Install Guide
For complete owners manual go to www.libav.com or use a QR code reader to
Important notice:
Do not attempt to disassemble or alter the housing. There are no user-serviceable parts
inside the unit. Doing so will void your warranty.
To minimize the possibility of equipment damage from electrostatic discharge (ESD), all source and
destination equipment must be powered off during installation.
Do not connect the device to a telecommunication outlet wired to unrelated equipment. Doing so may
damage the unit or any connected equipment. Ensure all connected twisted pair cabling is straight-through
(point-to-point).
Allow proper ventilation to reduce the risk of thermal failure.
This guide is for quick installation only.
access the manual via QR code below.
Scan QR Code with your Smart-phone or Tablet
