- Page 1 DL-UHDILC Owners Manual Rev 171213 11675 Ridgeline Dr. Toll-Free: 800-530-8998 Colorado Springs, CO 80921 Fax: 719-260-0075 supportlibav@libav.com...
-
Page 2: Important Safety Instructions
DL-UHDILC Owners Manual Important Safety Instructions 1. Read these instructions – All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions – The safety and operating instructions should be retained for future reference. - Page 3 DL-UHDILC Owners Manual 26. When the apparatus is not in use or during its relocation, take care of the power cord and plugs; e.g. tie up the power cord with cable tie or similar. The tie must be free from sharp edges and the like that might cause abrasion of the power cord.
-
Page 4: Table Of Contents
Installation Instructions ��������������������������������������������������������������������������������������������������������������������������������������������� 9 Basic Installation 9 RS232 Connections 9 Application Diagram ����������������������������������������������������������������������������������������������������������������������������������������������� 10 DL-UHDILC Configuration Software Usage ��������������������������������������������������������������������������������������������������������������� 11 Overview 11 Downloading DL-UHDILC Configuration Software 11 Making a PC Connection 11 Running Configuration Software 11... -
Page 5: Product Overview
The DigitaLinx DL-UHDILC is an HDMI in-line controller that can automate room peripherals and sink devices when a video signal is introduced to the unit. The DL-UHDILC is 4K compatible, supports HDCP version 2.2, has an analog and digital de-embedded audio output and has 15 built in EDID presets that can be adjusted by the rotary dial on the front panel. -
Page 6: Front And Rear Panels
HDMI IN - HDMI Video Input; connects to video source EDID - Rotary dial for 15 resolution presets • The EDID preset chart is located on the bottom of the DL-UHDILC S/PDIF OUT - Digital audio de-embedded output; connects to an AVR or audio amplifier... -
Page 7: Back Panel
• NOTE: The RS232 port can be configured by connecting a computer with a serial to USB adapter to the DL-UHDILC RS232 port and using the Display Configuration software to configure the port. The serial upload software is located on the DL-UHDILC product page Online at www.libav.com... -
Page 8: Edid Management
DL-UHDILC Owners Manual EDID Management The EDID rotary dials allows for EDID management so the source can sync with the desired video resolution of the system. If EDID copy fails then 1080p/60Hz Stereo EDID settings will be provided to the source... -
Page 9: Installation Instructions
• NOTE: The RS232 port on the DigitaLinx DL-UHDILC must be configured by connecting a computer to the RS232 port of the DL- UHDILC and by using the DL-UHDILC Configuration Software which is located on the DL-UHDILC product page Online at www.libav. -
Page 10: Application Diagram
DL-UHDILC Owners Manual DL-UHDILC IN-LINE HDMI CONTROLLER Application Diagram LAPTOP AUDIO AMP HDMI RELAY AUDIO RS232 FRONT BACK PROJECTOR SCREEN PROJECTOR... -
Page 11: Dl-Uhdilc Configuration Software Usage
DL-UHDILC. Making a PC Connection To connect a PC to the DL-UHDILC RS232 port, a DB9 (RS232) to USB adapter is required. The Liberty 120-DA-0004 RS232 to USB adapter can be used for this. Once the RS232 to USB adapter has been installed on the PC, connect the DB9 connector on the USB adapter to the DB9 connector of the DB9 to phoenix adapter that came in the DL-UHDILC box. -
Page 12: Serial Settings For Dl-Uhdilc
USB to RS232 is connected to on the computer. The default baud rate for the DL-UHDILC is 57600. Enter in 57600 in the Baud rate field and click Connect. If you are successfully connected to the unit, a green light will appear next the Connect button and a pop up... -
Page 13: Configuring Rs232 Serial Commands
Once you have entered in the Baud Rate of the display device in the software, the DL-UHDILC default baud rate setting will be changed to the same rate setting as well. The pop up window will instruct you to connect the serial port again. - Page 14 DL-UHDILC Owners Manual Enter the displays POWER ON and OFF/STANDBY command for the display device in the Power on and Power off field. Serial commands for displays and projectors are provided by the display manufacturer and can be found in the products instructional documentation.
-
Page 15: Configuring System Timeout
Configuring System Timeout By default system timeout is set to 3 minutes. After there is no present video signal passing through the DL-UHDILC for 3 minutes the system will transmit the Power off command to the display or projector and trigger the second relay port switch. -
Page 16: Technical Specifications
DL-UHDILC Owners Manual Technical Specifications VIDEO Video Inputs (1) HDMI Video Input Connector (1) HDMI type A Video Output (1) HDMI (1) HDMI type A Video Output Connector 600Mhz Maximum Pixel Clock Output Resolution Support 4096x2160 24/25/30/50/60Hz; 3840x2160 24/25/30/50/60Hz; 1920x1200 60Hz; 1920x1080 24/25/30/50/60Hz; 1280x720 24/25/30/50/60Hz;... - Page 17 DigitaLinx is a brand of: 11675 Ridgeline Drive Colorado Springs, Colorado 80921 USA Phone: 719-260-0061 Fax: 719-260-0075 Toll-Free: 800-530-8998 Email: supportlibav@libav.com...
