2000/2100 Series
Digitalinx IP Network Switch

Configuration Guide

Rev 191203
11675 Ridgeline Dr.
Toll-Free: 800-530-8998
Colorado Springs, CO 80921
Fax: 719-260-0075
supportlibav@libav.com

Advertisement

Table of Contents
loading

Related Manuals for DigitaLinx IP 2000 Series

Summary of Contents for DigitaLinx IP 2000 Series

  • Page 1: Configuration Guide

    2000/2100 Series Digitalinx IP Network Switch Configuration Guide Rev 191203 11675 Ridgeline Dr. Toll-Free: 800-530-8998 Colorado Springs, CO 80921 Fax: 719-260-0075 supportlibav@libav.com...

  • Page 2: Table Of Contents

    Multiple Switch Networking ..........................Cascading Network Switches ��������������������������������������������������������������������������������������������������������������������������� Stacking Network Switches ���������������������������������������������������������������������������������������������������������������������������� Open Network Ports Required �������������������������������������������������������������������������������������������������������������������������������� Digitalinx IP Device Configuration ������������������������������������������������������������������������������������������������������������������������ Cisco SG350X / SG550X Configurations ���������������������������������������������������������������������������������������������������������������� Single Switch Configuration ����������������������������������������������������������������������������������������������������������������������������������� Enable Advanced Display Mode ........................Disable 802.3 Energy Efficient Ethernet (EEE) ....................
  • Page 3 Digitalinx IP Network Switch Guide Multi Switch Configuration - Extended Switch Settings������������������������������������������������������������������������������ Enable Advanced Display Mode ......................Disable 802.3 Energy Efficient Ethernet (EEE) ..................Enable Multicast Forwarding ....................... Enable IGMP Snooping / Querier ......................Configure IGMP Snooping ........................Unregistered Multicast ........................
  • Page 4 Digitalinx IP Network Switch Guide Multi Switch Configuration - Core Switch Settings �������������������������������������������������������������������������������������������� Resetting to Factory Defaults ........................IGMP Configuration ............................ VLAN Configuration ............................ PoE Configuration ............................Reboot Switch ............................Multi Switch Configuration - Extended Switch Settings������������������������������������������������������������������������������������� Resetting to Factory Defaults ........................

  • Page 5: Ethernet Switch Planning

    Digitalinx IP networks. Basic Ethernet Switch Configuration Settings Below is a list of basic Ethernet settings for L2/L3 switches that can be used to configure switches for Digitalinx IP devices.

  • Page 6: Power Over Ethernet (Poe)

    The PSE will also manage the power requirements for the attached devices. • A PD is a device powered by a PSE. Examples include Digitalinx IP encoders and decoders, as well as wireless access points. The electric modules that receive power from the PSE are called PD modules.

  • Page 7: Using A Router

    Wireless Access Devices In order for the Digitalinx IP Control software on an iPad to connect to the IP video network, it is necessary to deploy a wireless access point (WAP) on the A/V network. Set up an SSID and password for connectivity but Internet access for the WAP is not required.

  • Page 8: Single Switch Networking

    Digitalinx IP Network Switch Guide A/V Network Topology 2000 / 2100 series systems can be deployed in a single or multi switch configuration. Single Switch Networking Below is an example of a A/V network topology using only one 24 port L2/L3 Managed Poe Network switch.

  • Page 9: Multiple Switch Networking

    Digitalinx IP Network Switch Guide Multiple Switch Networking In a multi switch environment, two or more switches may be uplinked together to become one large A/V network. There are two methods that we address in this configuration guide; cascading and stacking.

  • Page 10: Stacking Network Switches

    Digitalinx IP Network Switch Guide Stacking Network Switches Below is an example of two switches stacked together with one Fiber cable jumper. In this configuration guide there are separate configurations for the core and extended switch when stacking switches together however when using a stacked network configuration the core network switch will manage the entire network.

  • Page 11: Open Network Ports Required

    Digitalinx IP Network Switch Guide Open Network Ports Required Below is a detailed list of the required open ports for DigitalinxIP series devices. These ports must be opened to communicate with DigitalinxIP devices on a LAN with a router and/or firewall.

  • Page 12: Digitalinx Ip Device Configuration

    IPEXCB product page under the Software tab. To assist you in deploying an IP video system with the IP Configurator tool, the Digitalinx IP Deployment Guide can guide is available for download at www�libav�com on the product page for the IPEXCB under the Documentation tab.

  • Page 13: Cisco Sg350X / Sg550X Configurations

    Digitalinx IP Network Switch Guide Cisco SG350X / SG550X Configurations Cisco SG switches can be configured for use in a single switch or multi switch environment. The SG series switches features easy to use web interfaces so configuration is easier to manage versus command line interface (CLI) programming using Cisco OS.

  • Page 14: Enable Advanced Display Mode

    Digitalinx IP Network Switch Guide Enable Advanced Display Mode Select the drop down option ADVANCED in the Display Mode drop down menu in the upper right hand corner of the web interface. Disable 802.3 Energy Efficient Ethernet (EEE) Navigate to Port Management > Green Ethernet > Properties.

  • Page 15: Enable Multicast Forwarding

    Digitalinx IP Network Switch Guide Enable Multicast Forwarding Navigate to Multicast > Properties. Check Enable for Bridge Multicast Filtering Status. Click the Apply button.

  • Page 16: Enable Igmp Snooping / Querier

    Digitalinx IP Network Switch Guide Enable IGMP Snooping / Querier Navigate to Multicast > IGMP Snooping. Check Enable for IGMP Snooping / Querier Status. Click the Apply button. For next steps you will need to configure the VLAN for Snooping, Querier and Fast Leave.

  • Page 17: Configure Igmp Snooping For Single Switch Network

    Digitalinx IP Network Switch Guide Configure IGMP Snooping for Single Switch Network Check Enable for IGMP Snooping Status� Uncheck Enable for MRouter Ports Auto Learn� Check Enable for Immediate leave� Check Enable for IGMP Querier Status� NOTE: The SG550X series switches will also ask for a Query Interval, enter in 60 for the Query interval Select V2 for IGMP Querier Version�...

  • Page 18: Unregistered Multicast

    Digitalinx IP Network Switch Guide Unregistered Multicast Navigate to Multicast > Unregistered Multicast. Select Filtering for all ports. Click the Apply button. PoE Settings and Configuration By default Cisco SG switches turns PoE on all ports ON so there is no additional configuration required.

  • Page 19: Save Startup Configuration

    Digitalinx IP Network Switch Guide Save Startup Configuration At the top of the web interface is a SAVE option that will flash whenever a change has been made to the startup config. Click the SAVE button to save current running configuration.

  • Page 20: Backing Up Startup Configuration

    RUNNING versus STARTUP CONFIGURATION: Keep in mind when you update the startup config file the switch setting stays in place after a reboot. When updating running config it only updates what is currently running and if the switch is rebooted the settings are lost. Always save settings to startup configuration for Digitalinx IP networks.

  • Page 21: Reboot Switch

    Digitalinx IP Network Switch Guide Reboot Switch Navigate to Administration > Reboot. Click the Apply button� Click the OK button to confirm the reboot. After the switch reboots, it will run with the confirmed configuration. It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly.

  • Page 22: Multi Switch Configuration - Core Switch Settings

    Digitalinx IP Network Switch Guide Multi Switch Configuration - Core Switch Settings Connect a PC to the network switch using a Category cable. The default IP address of the switch is 192.168.1.254. Set a static IP address for the PC to ensure it is in the same IP range as the switch, such as 192.168.1.42.

  • Page 23: Enable Advanced Display Mode

    Digitalinx IP Network Switch Guide Enable Advanced Display Mode Select the drop down option ADVANCED in the Display Mode drop down menu in the upper right hand corner of the web interface. Disable 802.3 Energy Efficient Ethernet (EEE) Navigate to Port Management > Green Ethernet > Properties.

  • Page 24: Enable Multicast Forwarding

    Digitalinx IP Network Switch Guide Enable Multicast Forwarding Navigate to Multicast > Properties. Check Enable for Bridge Multicast Filtering Status. Click the Apply button.

  • Page 25: Enable Igmp Snooping / Querier

    Digitalinx IP Network Switch Guide Enable IGMP Snooping / Querier Navigate to Multicast > IGMP Snooping. Check Enable for IGMP Snooping / Querier Status. Click the Apply button. For next steps you will need to configure the VLAN for Snooping, Querier and Fast Leave.

  • Page 26: Configure Igmp Snooping

    Digitalinx IP Network Switch Guide Configure IGMP Snooping Check Enable for IGMP Snooping Status� Uncheck Enable for MRouter Ports Auto Learn� Uncheck Enable for Immediate leave� Check IGMP Querier Status� NOTE: The SG550X series switches will also ask for a Query Interval, enter in 60 for the Query interval Check IGMP Querier Election Select V2 for IGMP Querier Version�...

  • Page 27: Unregistered Multicast

    Digitalinx IP Network Switch Guide Unregistered Multicast Navigate to Multicast > Unregistered Multicast. Select Filtering for all ports. Click the Apply button. PoE Settings and Configuration By default Cisco SG switches turns PoE on all ports ON so there is no additional configuration required.

  • Page 28: Save Startup Configuration

    Digitalinx IP Network Switch Guide Save Startup Configuration At the top of the web interface is a SAVE option that will flash whenever a change has been made to the startup config. Click the SAVE button to save current running configuration.

  • Page 29: Backing Up Startup Configuration

    RUNNING versus STARTUP CONFIGURATION: Keep in mind when you update the startup config file the switch setting stays in place after a reboot. When updating running config it only updates what is currently running and if the switch is rebooted the settings are lost. Always save settings to startup configuration for Digitalinx IP networks.

  • Page 30: Reboot Switch

    Digitalinx IP Network Switch Guide Reboot Switch Navigate to Administration > Reboot. Click the Apply button� Click the OK button to confirm the reboot. After the switch reboots, it will run with the confirmed configuration. It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly.

  • Page 31: Multi Switch Configuration - Extended Switch Settings

    Digitalinx IP Network Switch Guide Multi Switch Configuration - Extended Switch Settings Disconnect the PC computer from the Core switch and connect into the Extended switch to configure. NOTE: Do not connect the two switches together at this stage in the configuration, you will need to set the IP of the extended switch to a different address first before you connect them together.

  • Page 32: Enable Advanced Display Mode

    Digitalinx IP Network Switch Guide Enable Advanced Display Mode Select the drop down option ADVANCED in the Display Mode drop down menu in the upper right hand corner of the web interface. Disable 802.3 Energy Efficient Ethernet (EEE) Navigate to Port Management > Green Ethernet > Properties.

  • Page 33: Enable Multicast Forwarding

    Digitalinx IP Network Switch Guide Enable Multicast Forwarding Navigate to Multicast > Properties. Check Enable for Bridge Multicast Filtering Status. Click the Apply button.

  • Page 34: Enable Igmp Snooping / Querier

    Digitalinx IP Network Switch Guide Enable IGMP Snooping / Querier Navigate to Multicast > IGMP Snooping. Check Enable for IGMP Snooping / Querier Status. Click the Apply button. For next steps you will need to configure the VLAN for Snooping, Querier and Fast Leave.

  • Page 35: Configure Igmp Snooping

    Digitalinx IP Network Switch Guide Configure IGMP Snooping Check Enable for IGMP Snooping Status� Check Enable for MRouter Ports Auto Learn� Check Enable for Immediate leave� Uncheck IGMP Querier Status� Click the Apply then the Close buttons.

  • Page 36: Unregistered Multicast

    Digitalinx IP Network Switch Guide Unregistered Multicast Navigate to Multicast > Unregistered Multicast. Select Filtering for all ports except the port that is uplinked to the core switch. In this example the port used to connect to the core switch is port 21.

  • Page 37: Save Startup Configuration

    Digitalinx IP Network Switch Guide Save Startup Configuration At the top of the web interface is a SAVE option that will flash whenever a change has been made to the startup config. Click the SAVE button to save current running configuration to the startup configuration.

  • Page 38: Reboot Switch

    Digitalinx IP Network Switch Guide Reboot Switch Navigate to Administration > Reboot. Click the Apply button� Click the OK button to confirm the reboot. After the switch reboots, it will run with the confirmed configuration. It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly.

  • Page 39: Cisco C2960 Switch Configurations

    Digitalinx IP Network Switch Guide Cisco C2960 Switch Configurations The Cisco C2960 switch models do not feature an easy to use web interface in order to program switch settings. For these switches you will need to enter in the settings using command line interface (CLI) with a computer connected to the CONSOLE port of the Cisco switch with a rollover / yost cable.

  • Page 40: Ip Igmp Snooping Querier

    Digitalinx IP Network Switch Guide IGMP Settings... #ip igmp snooping vlan 1 immediate-leave #ip igmp snooping querier address 192.168.22.222 #ip igmp snooping querier Save Startup Config... #write Reboot the switch... #reload It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly.

  • Page 41: Multi Switch Configuration - Core Switch Settings

    Digitalinx IP Network Switch Guide Multi Switch Configuration - Core Switch Settings The global settings (Energy Savings, Flooding, PoE) for the core switch settings in a multi switch configuration will be the same as the single switch configuration settings accept for the IGMP settings. See below.

  • Page 42: Luxul Switch Configurations

    Digitalinx IP Network Switch Guide Luxul Switch Configurations Luxul Ethernet switches can be used in single switch networking or multiple switch networking. NOTE: Luxul switches are not supported for use with video walls use. In the setup examples in this guide, the AMS-4424P switch was used for configuration.

  • Page 43: Resetting To Factory Defaults

    Digitalinx IP Network Switch Guide Resetting to Factory Defaults Navigate to Administration > Factory Defaults. Click the Yes button.

  • Page 44: Igmp Snooping / Fast Leave Configuration

    Digitalinx IP Network Switch Guide IGMP Snooping / Fast Leave Configuration Navigate to Configuration > IPMC > IGMP Snooping > Basic Configuration. Check the Snooping Enabled box. Uncheck the Unregistered IPMCv4 Flooding Enabled box. Check the Fast Leave box in the all ports (*) row.

  • Page 45: Vlan Configuration

    Digitalinx IP Network Switch Guide VLAN Configuration Navigate to Configuration > IPMC > IGMP Snooping > VLAN Configuration. Click the Add New IGMP VLAN button. Enter 1 in the VLAN ID box. Check the Snooping Enabled box. Check the Querier Election box.

  • Page 46: Save Configuration

    Digitalinx IP Network Switch Guide Save Configuration Navigate to Administration > Configuration > Save startup-config. Click the Save Configuration button.

  • Page 47: Reboot Switch

    Digitalinx IP Network Switch Guide Reboot Switch Navigate to Administration and click Reboot It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly. This double verification process will help you be sure the switch settings are always 100% and will cut...

  • Page 48: Multi Switch Configuration - Core Switch Settings

    Digitalinx IP Network Switch Guide Multi Switch Configuration - Core Switch Settings The default IP address of the switch is 192.168.0.4. Set a static IP address of the PC to ensure it is in the same IP range as the switch, such as 192.168.0.42.

  • Page 49: Resetting To Factory Defaults

    Digitalinx IP Network Switch Guide Resetting to Factory Defaults Navigate to Administration > Factory Defaults. Click the Yes button.

  • Page 50: Igmp Snooping / Fast Leave Configuration

    Digitalinx IP Network Switch Guide IGMP Snooping / Fast Leave Configuration Navigate to Configuration > IPMC > IGMP Snooping > Basic Configuration. Check the Snooping Enabled box. Uncheck the Unregistered IPMCv4 Flooding Enabled box. Check the Fast Leave box in the all ports (*) row.
  • Page 51 Digitalinx IP Network Switch Guide Locate the port where the extended switch will be connected to. Uncheck the Fast Leave box for the port. Click the Save button.

  • Page 52: Vlan Configuration

    Digitalinx IP Network Switch Guide VLAN Configuration Navigate to Configuration > IPMC > IGMP Snooping > VLAN Configuration. Click the Add New IGMP VLAN button. Enter 1 in the VLAN ID box. Check the Snooping Enabled box. Check the Querier Election box.

  • Page 53: Save Configuration

    Digitalinx IP Network Switch Guide Save Configuration Navigate to Administration > Configuration > Save startup-config. Click the Save Configuration button.

  • Page 54: Reboot Switch

    Digitalinx IP Network Switch Guide Reboot Switch Navigate to Administration and click Reboot It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly. This double verification process will help you be sure the switch settings are always 100% and will cut...

  • Page 55: Multi Switch Configuration - Extended Switch Settings

    Digitalinx IP Network Switch Guide Multi Switch Configuration - Extended Switch Settings Disconnect the PC computer from the Core switch and connect into the Extended switch to configure. NOTE: Do not connect the two switches together at this stage in the configuration, you will need to set the IP of the extended switch to a different address first before you connect them together.

  • Page 56: Resetting To Factory Defaults

    Digitalinx IP Network Switch Guide Resetting to Factory Defaults Navigate to Administration > Factory Defaults. Click the Yes button.

  • Page 57: Igmp Snooping / Fast Leave Configuration

    Digitalinx IP Network Switch Guide IGMP Snooping / Fast Leave Configuration Navigate to Configuration > IPMC > IGMP Snooping > Basic Configuration. Check the Snooping Enabled box. Uncheck the Unregistered IPMCv4 Flooding Enabled box. Check the Fast Leave box in the all ports (*) row.

  • Page 58: Vlan Configuration

    Digitalinx IP Network Switch Guide VLAN Configuration Navigate to Configuration > IPMC > IGMP Snooping > VLAN Configuration. Click the Add New IGMP VLAN button. Enter 1 in the VLAN ID box. Check the Snooping Enabled box. Uncheck the Querier Election box.

  • Page 59: Save Configuration

    Digitalinx IP Network Switch Guide Save Configuration Navigate to Administration > Configuration > Save startup-config. Click the Save Configuration button.

  • Page 60: Reboot Switch

    Digitalinx IP Network Switch Guide Reboot Switch Navigate to Administration and click Reboot It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly. This double verification process will help you be sure the switch settings are always 100% and will cut...

  • Page 61: Niveo Switch Configurations

    Digitalinx IP Network Switch Guide Niveo Switch Configurations Niveo Ethernet switches can be used in single switch networking or multiple switch networking. NOTE: The Niveo 8/16 port PoE switch does not support the PoE protocols used by the IPEXCB, IPEX2001 and IPEX2002 so it is not recommended for use.

  • Page 62: Resetting To Factory Defaults

    Digitalinx IP Network Switch Guide Resetting to Factory Defaults Navigate to Maintenance > Factory Defaults. Click the Yes button. IGMP Configuration Navigate to Configuration > IPMC > IGMP Snooping > Basic Configuration. Check the Snooping Enabled box. Uncheck the Unregistered IPMCv4 Flooding Enabled box.

  • Page 63: Vlan Configuration

    Digitalinx IP Network Switch Guide VLAN Configuration Navigate to Configuration > IPMC > IGMP Snooping > VLAN Configuration. Click the Add New IGMP VLAN button. Enter 1 in the VLAN ID box. Check the Snooping Enabled box. Check the Querier Election box.

  • Page 64: Poe Configuration

    Digitalinx IP Network Switch Guide PoE Configuration By default Niveo switches turns PoE on all ports ON so there is no additional configuration required. To change any port PoE parameters, navigate to the Maintenance>PoE>PoE to adjust settings. Reboot Switch Navigate to Administration and click Restart Device It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly.

  • Page 65: Multi Switch Configuration - Core Switch Settings

    Digitalinx IP Network Switch Guide Multi Switch Configuration - Core Switch Settings The default IP address of the switch is 192.168.2.1. Set a static IP address of the PC to ensure it is in the same IP range as the switch, such as 192.168.2.42.

  • Page 66: Resetting To Factory Defaults

    Digitalinx IP Network Switch Guide Resetting to Factory Defaults Navigate to Maintenance > Factory Defaults. Click the Yes button. IGMP Configuration Navigate to Configuration > IPMC > IGMP Snooping > Basic Configuration. Check the Snooping Enabled box. Uncheck the Unregistered IPMCv4 Flooding Enabled box.
  • Page 67 Digitalinx IP Network Switch Guide Locate the port where the extended switch will be connected to. Uncheck the Fast Leave box for the port. In our example we are using port 48 to connect to the extended switch Click the Save button.

  • Page 68: Vlan Configuration

    Digitalinx IP Network Switch Guide VLAN Configuration Navigate to Configuration > IPMC > IGMP Snooping > VLAN Configuration. Click the Add New IGMP VLAN button. Enter 1 in the VLAN ID box. Check the Snooping Enabled box. Check the Querier Election box.

  • Page 69: Poe Configuration

    Digitalinx IP Network Switch Guide PoE Configuration By default Niveo switches turns PoE on all ports ON so there is no additional configuration required. To change any port PoE parameters, navigate to the Maintenance>PoE>PoE to adjust settings. Reboot Switch Navigate to Administration and click Restart Device It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly.

  • Page 70: Multi Switch Configuration - Extended Switch Settings

    Digitalinx IP Network Switch Guide Multi Switch Configuration - Extended Switch Settings Disconnect the PC computer from the Core switch and connect into the Extended switch to configure. NOTE: Do not connect the two switches together at this stage in the configuration, you will need to set the IP of the extended switch to a different address first before you connect them together.

  • Page 71: Resetting To Factory Defaults

    Digitalinx IP Network Switch Guide Resetting to Factory Defaults Navigate to Maintenance > Factory Defaults. Click the Yes button. IGMP Configuration Navigate to Configuration > IPMC > IGMP Snooping > Basic Configuration. Check the Snooping Enabled box. Uncheck the Unregistered IPMCv4 Flooding Enabled box.

  • Page 72: Vlan Configuration

    Digitalinx IP Network Switch Guide VLAN Configuration Navigate to Configuration > IPMC > IGMP Snooping > VLAN Configuration. Click the Add New IGMP VLAN button. Enter 1 in the VLAN ID box. Check the Snooping Enabled box. Uncheck the Querier Election box.

  • Page 73: Poe Configuration

    Digitalinx IP Network Switch Guide PoE Configuration By default Niveo switches turns PoE on all ports ON so there is no additional configuration required. To change any port PoE parameters, navigate to the Maintenance>PoE>PoE to adjust settings. Reboot Switch Navigate to Administration and click Restart Device It is best practice to check and confirm the switch settings after a reboot to be sure the system settings were applied correctly.

  • Page 74: Pakedge Sx Series Switch Configurations

    Currently, Pakedge SX Series Ethernet switches can only operate in a single switch networking configuration with the Digitalinx IP video products. NOTE that not all ports on the Pakedge SX switches are PoE ports so Digitalinx IP devices may have to be powered by the supplied power adapters.

  • Page 75: Resetting To Factory Defaults

    Digitalinx IP Network Switch Guide Resetting to Factory Defaults Navigate to Management > Maintenance� Click the Factory Default tab. Click the Reset System button. Click the OK button and wait for the switch to reboot.

  • Page 76: Igmp Configuration

    Digitalinx IP Network Switch Guide IGMP Configuration Navigate to Traffic > IGMP. In the IGMP Snooping tab, select Enable from the IGMP Status dropdown list. Click the Apply button.
  • Page 77 Digitalinx IP Network Switch Guide Click the OK button in the popup window. Once IGMP is enabled, click the pencil icon on the far right of the VLAN ID 1 group.
  • Page 78 Digitalinx IP Network Switch Guide Scroll to the bottom of the new page. In the Unknown Multicast Drop dropdown list, select Drop. Click the Apply button.

  • Page 79: Fast Leave Configuration

    Digitalinx IP Network Switch Guide Fast Leave Configuration Click on the Fast Leave tab. Click on each RJ45 icon, which will turn blue. Click the Apply button. After the changes are applied, a green circle will appear under each RJ45 icon.

  • Page 80: Poe Configuration

    Digitalinx IP Network Switch Guide PoE Configuration NOTE that not all ports on the Pakedge SX switches are PoE ports so Digitalinx IP devices may have to be powered by the supplied power adapters. Navigate to Ports > PoE� Select the ports not used to power PoE devices by clicking the corresponding icons. Once an icon clicked, it will turn...
  • Page 81 Digitalinx IP Network Switch Guide Scroll to the bottom of the page. In the PoE Power Status dropdown list, select Disable. Click the Apply button. The first green circle for ports 15, 16 will change to gray, which indicates PoE is disabled on these ports.
