- Page 1 User’s Manual 4X1 HDMI Switcher Part #: DL-HDS41...
- Page 2 Congratulations on your purchase of a DigitaLinx™ Switch. This manual contains information that will assist you in the installation and operation of this product. Please inspect the contents of the package to ensure all required material is present. Contents: Each DigitaLinx™ Switch package contains the following items...
- Page 3 TABLE OF CONTENTS Table of Contents Product Description and General Specifications Environmental Reliability Specifications Features Installation Mechanical Specifications Technical Specifications Warranty Information Troubleshooting Contents...
- Page 4 Product Description and General Specifications This DigitaLinx™ 4:1 Switching device allows up to 4 Digital Media inputs to share one Digital Display. The inputs can be easily selected for display by using the included IR remote, the manual button on the device itself, or by use of RS-232 protocol with a personal computer.
-
Page 5: Environmental Reliability Specifications
-20°C to 45°C, non-condensing humidity levels from 5-95%, and an altitude ceiling of 3,000 meters (9,840 feet) The DigitaLinx™ Switcher is expected to function for more than 50,000 hours of use at a 90% confidence level. The device is tested to the identical standards for testing LCD monitors. -
Page 6: Signal Amplification
1080p resolution. Compact and Practical Design The DigitaLinx™ Switch is designed with all inputs and outputs located on the rear of the device. This will allow the device to be mounted in a rack and efficiently route the cabling. The front of the device contains the IR remote sensor, manual switch and LED indicator lights for RS232 and channel indicators. -
Page 7: Installation
1.) Ensure all the digital media sources and displays are turned off. 2.) Connect all digital media sources to the input ports of the DigitaLinx™ switcher. 3.) Connect the digital display to the output port of the DigitaLinx™... -
Page 8: Mechanical Specifications
Mechanical Specifications Dimensions DL-HDS41 : 330x105x30 mm DC 5V : DC Power 5V Input RS-232 : Com Port For Switch Function Control HDMI IN CH1~4 : HDMI Input Signal HDMI OUT : HDMI Output Signals LED CH1~4 : Selected Channel Indication... -
Page 9: Technical Specifications
Technical Specifications Frequency Bandwidth: 1.65 Gbps Supporting Graphic Resolution: Up to computer UXGA (1600x1200 @ 75Hz) Up to display 1080p60 (2200x1125@60Hz) Inputs: HDMI Type A receptacle (single link) 4 ports Output: HDMI Type A receptacle (single link) 1 port Power Supply: 5VDC, 1.2 A Adapter included Infrared Remote Control included HDCP (High-bandwidth Digital Content Protection) Compliant Connector pin assignment for... -
Page 10: Warranty Information
Warranty Information 1 (One) Year Warranty Liberty Wire & Cable warrants this HDMI Switch to be free from defects in workmanship and materials, under normal use and service, for a period of one (1) year from the date of purchase from Liberty Wire & Cable or its authorized resellers. -
Page 11: Troubleshooting
Troubleshooting The DigitaLinx™ Switcher is designed for years of trouble free service, please reference the troubleshooting chart below if experiencing issues with the device. Symptom Solution Device will not Ensure the 5VDC power adapter is plugged in, the power indicator LED... - Page 12 © 2005 Liberty Wire & Cable. All Rights Reserved. Liberty Wire & Cable 11675 Ridgeline Drive Colorado Springs, CO 80921 800-530-8998 www.libertycable.com...
