1.2

Description

The IP-4PCI2E Series combines the high performance and exceptional
®
value of Intel 875P chipset with a full-featured, new generation, industrial
board. The Intel
® ®
Intel Pentium
memory base on the FSB 533/800MHz operation supports dual channel
DDR266/333/400 SDRAM interface. In the meantime, the 875P chipset has
an external graphics device on AGP slot. The IP-4PCI2E system memory
size can be up to 4GB DDR memory, onboard Intel
Ethernet controller (support 10/100/1000 Base-TX Ethernet), Audio and with
2 COM ports, besides the IP-4PCI2E add one 6-pins connector that can
extend to front of chassis for KB & MS.
The 6300ESB I/O Controller Hub employs the Intel
Architecture to make a direct connection from the connector to the device,
such as the two IDE ports (ATA/33 or ATA/66 or ATA/100), four USB ports
that are supported USB 1.1/2.0 standard meets the performance, two Serial
ATA ports and PCI/PCI-X slots.
1.3 Features
1.3.1 Chipsets Features
The IP-4PCI2E is base on the Intel
AGP8X slot, Gigabit Ethernet, Audio function. The features of chipset are as
below:
Enhanced AGP8X slot & system performance:
- Support FSB 533/800 MHz
Memory:
- DDR266/333/400 unbuffer ECC and non-ECC DDR SDRAM
- Dual channel up to 4.0GB Max. Memory
- 4 DIMM sockets
®
advanced 875P chipset support regular socket 478-pins
®
4 / Celeron processors of 2.4GHz and up to 3.2GHz, that
®
®
875P chipset, offers users the
3
Introduction
82547GI Gigabit
®
Accelerated Hub
