1. The "LOAD SETUP DEFAULTS" function loads the system default data directly
from
ROM and initializes the associated hardware properly. This function is necessary
when you accept this mainboard, or the system CMOS data will corrupt.
STANDARD CMOS SETUP
BIOS FEATURES SETUP
CHIPSET FEATURES SETUP
POWER MANAGEMENT SETUP
PNP/PCI CONFIGURA
INTEGRATED PERIPH
LOAD SETUP DEFAULTS
ESC: QUIT
F10:Save & Exit Setup
Load Setup Defaults Except Standard COMS SETUP
2. KBPO(KeyBoard Power On) Function : There is a basic requirement that the
" +5V SB" power of the ATX power supply must be > = 0.1A (100mA).
Please refer to chapter 2-5 for detail.

Read me first

ROM PCI/ISA BIOS
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
SUPERVISOR PASSWORD
USER PASSWORD
IDE HDD AUTO DETECTION
HDD LOW LEVEL FORMAT
Load SETUP Default (Y/N)?
(Shift)F2 :Change Color
LOAD SETUP DEFAULT
ETUP
Y
SAVING
:SELECT ITEM

Advertisement

Table of Contents
loading

Related Manuals for EPOX EP-58MVP3C-M

Summary of Contents for EPOX EP-58MVP3C-M

  • Page 1: Read Me First

    Read me first 1. The "LOAD SETUP DEFAULTS" function loads the system default data directly from ROM and initializes the associated hardware properly. This function is necessary when you accept this mainboard, or the system CMOS data will corrupt. ROM PCI/ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC.
  • Page 2 Apollo MVP3 AGPset MVP3C EP-58 ISA/PCI/AGP MainBoard with Onboard PCI IDE and Super Multi-I/O. TRADEMARK All products and company names are trademarks or registered trademarks of their respective holders. The specification is subject to change without notice. V021...

  • Page 3: Package Checklist

    Package Checklist Please check your package which should include all items listed below. If you find any item damaged or missed, please contact your supplier. One mainboard One manual One IDE ribbon cable One floppy ribbon cable One Parallel port ribbon cable One Serial port ribbon cable(COM1,COM2) One PS/2 mouse cable(Optional) One AGP driver diskette...

  • Page 4: Table Of Contents

    Contents page Chapter 1 - Introduction............Chapter 2 - Hardware Design ..........2-1 Mainboard Layout..............2-1 2-2 Connectors and Jumpers............2-3 2-3 System Memory Configuration..........2-5 2-4 ATX Power ON/OFF Control............ 2-6 2-5 External Modem Ring-in Power ON and Keyboard Power ON Functions................

  • Page 5: Chapter 1 - Introduction

    Introduction 1-1 Chapter 1 Introduction This mainboard is a high performance system hardware based on Intel Pentium processor and is equipped with an AGP slot, four PCI slots, three standard ISA slots, Super Multi-I/O controller and dual port PCI-IDE connectors for the future expansion. The hardware dimension is 220mm x 260mm with a four-layer-design technology.

  • Page 6: Chapter 2 - Hardware Design

    Hardware Design Chapter 2 Hardware design 2-1 Mainboard Layout This mainboard is designed with VIA Apollo MVP3 AGP/PCIset chipset which is developed by VIA Corporation to fully support Pentium Processor PCI/ ISA system. By providing a massive increase in the bandwidth available between the video card and the processor (66MHz), the unique feature of AGP supported by VIA Apollo MVP3 chipset improves the speed of rendering and texturing for 3D graphics.The chipset also provides an integrated IDE controller with two high...
  • Page 7 EP-58MVP3C-M EP-58MVP3C-M Layout COM2 BIOS CONN. COM1 W83877TF PRINTER FDD CONN. Primary IDE Secondary IDE 82C586B VT82C598AT 2.1V 2.2V 2.8V 2.9V 3.2V 5 10 CACHE J4 : CPU FAN POWER - ON J6 : CHASSIS FAN Multiplier Bus Clock RESET SPEAKER KEYLOCK IR CONN.

  • Page 8: Connectors And Jumpers

    Hardware Design 2-2 Connectors and Jumpers This section describes the connectors and jumpers equipped in the mainboard. Please refer to Figure 2-1 for the location of each connector and jumper. Pentium / MMX Cyrix / IBM AMD K5 / K6 6x86L idt - C6 6x86MX...
  • Page 9 EP-58MVP3C-M Reset Switch - Closed to restart system. Speaker - connect to the system's speaker for beeping. 1. Speaker 2. N/C 3. GND 4. VCC KeyLock - Keyboard lock switch & Power LED connector. 1. Power LED(+) 2. N/C 3. GND 4.

  • Page 10: System Memory Configuration

    Hardware Design 2-3 System Memory Configuration This mainboard supports different type of settings for the system memory. The following figures and table provides all possible memory combinations. 1 2 1 2 1 2 1 2 > BANK 2 DIMM3 > DIMM2 BANK 1 >...

  • Page 11: Atx Power On/Off Control

    EP-58MVP3C-M 2-4 ATX Power ON/OFF Control This mainboard equips an ATX power connector which is a single 20-PIN input device for an ATX power supply (see Figure 2-2). An ATX power supply provides a build-in Remote Power ON/OFF function. To implement the function, a momen- tary switch which is normally open should be connected to the position J3(PIN 12, 13) as the system's power ON/OFF button.

  • Page 12: External Modem Ring-In Power On And Keyboard Power On Functions

    Here, we would like to suggest you push 2 keys at the same time.. 2.Intel ATX version 2.0 specification has recommended you use the power supply with 0.72A(720mA). With our EP-58MVP3C-M mainboard, the 5.0VSB standby power only has to be > = 0.1A (100mA) then you can enjoy this unique benefit.

  • Page 13: Integrated Pci Bridge

    EP-58MVP3C-M 2-6 Integrated PCI Bridge This mainboard utilizes VIA Apollo MVP3 AGP/PCIset chipset to support Intel Pentium Processor PCI/ISA system. The VIA Apollo MVP3 PCIset chipset consists of the 82C598AT system controller (TSC), and one 82C586B PCI ISA/ IDE Accelerator bridge chip. It provides an interface which translates CPU cycle into PCI bus cycle, and PCI burst read/write capability.

  • Page 14: Chapter 3 - Award Bios Setup

    AWARD BIOS 3-1 CHAPTER 3 AWARD BIOS SETUP Award's ROM BIOS provides a built-in setup program which allows user to modify the basic system configurations and hardware parameters. The modified data will be stored in a battery-backed CMOS RAM so that data will be retained even when the power is turned off.

  • Page 15: Standard Cmos Setup

    3-2 CHAPTER 3 3-1 STANDARD CMOS SETUP Choose "STANDARD CMOS SETUP" in the CMOS SETUP UTILITY Menu (Fig. 3-1). The STANDARD CMOS SETUP allows user to configure system setting such as the current date and time, type of hard disk installed, floppy type, and display type. Memory size is auto-detected by the BIOS and displayed for your reference.
  • Page 16 AWARD BIOS 3-3 ROM PCI/ISA BIOS(2A5LEPA9) BIOS FEATURES SETUP AWARD SOFTWARE, INC. Virus Warning : Disabled Video BIOS Shadow : Enabled CPU Internal Cache : Enabled C8000-CBFFF Shadow : Disabled External Cache : Enabled CC000-CFFFF Shadow : Disabled Quick Power On Self Test : Enabled D0000-D3FFF Shadow...
  • Page 17 3-4 CHAPTER 3 Quick Power On Self Test:This category speeds up Power On Self Test (POST) after you power on the computer. If it is set to Enable, BIOS will shorten or skip some checking items during POST. Enabled : Enable quick POST. Disabled: Normal POST.
  • Page 18 AWARD BIOS 3-5 Typematic Rate Setting This determines the typematic rate. Enabled Enable typematic rate and typematic delay programming. Disabled Disable typematic rate and typematic delay programming. The system BIOS will use default value of 2 items and the default is controlled by keyboard.

  • Page 19: Chipset Features Setup

    3-6 CHAPTER 3 C8000 - CBFFF Shadow : CC000 - CFFFF Shadow: D0000 - D3FFF Shadow: D4000 - D7FFF Shadow: D8000 - DBFFF Shadow: DC000 - DFFFF Shadow: These categories determine whether optional ROM will be copied to RAM by 16K byte or 32K byte per unit and the size depends on the chipset.
  • Page 20 AWARD BIOS 3-7 DRAM Timing: The default value is 60ns. 60ns : 2 (faster) Burst Wait State, for 60~70ns Fast Page Mode/EDO DRAM. 70ns : 3 (slower) Burst Wait State, for 70ns Fast Page Mode/EDO DRAM. : The default value is 2. SDRAM Cycle length 2 : 2 HCLKS.
  • Page 21 3-8 CHAPTER 3 : The amount of the system memory that the AGP card is AGP Aperture Size allowed to share. The options available are 4M, 8M, 16M, 32M, 64M, 128M, 256M. The default value is 64M. : The default value is 1X. AGP Transfer Mode 1X : 66MHz AGP transfer mode.

  • Page 22: Power Management Setup

    AWARD BIOS 3-9 3-4 POWER MANAGEMENT SETUP Choose the "POWER MANAGEMENT SETUP" in the CMOS SETUP UTILITY to display the following screen. This menu allows the user to modify the power management parameters and IRQ signals. In general, these parameters should not be changed unless it is absolutely necessary.
  • Page 23 3-10 CHAPTER 3 B. Time-out parameters : HDD Standby HDD Standby timer can be set from 1 to 15 minute(s). System Doze The "System Doze" mode timer starts to count when there is no "PM events" occurred. The valid time-out setting is from 1 minute up to 1 hour. System Suspend This function works only when the Pentium Procssor is installed.
  • Page 24 AWARD BIOS 3-11 RTC Alarm Resume This option allows you to have the system turn on at a preset time each day or on a certain day. This option is only available when used an ATX power supply. Enabled : The system will turn on at the preset time. Disabled : Normal Setting Date(of month) This field is to set the date that the system will turn on.

  • Page 25: Pnp/Pci Configuration

    3-12 CHAPTER 3 PM Events: AWARD BIOS defines 7 PM Events in the power management mode (Doze & suspend). The user can initialize any PM Events to be "Enable" or "Disable". When the system detects all of the enabled events do not have any activity, it will start the system Doze timer first if the "Power Management"...
  • Page 26 AWARD BIOS 3-13 Resource Controlled By:The default value is Manual. Manual: The field defines that the PNP Card's resource is controlled by manual. You can setup whether IRQ-X or DMA-X is assigned to PCI/ISA PNP or Legacy ISA Cards. Auto: If your ISA card and PCI card are all PNP cards. Set this field to "Auto". The BIOS will assign the interrupt resource automatically.

  • Page 27: Integrated Peripherals

    3-14 CHAPTER 3 3-6 INTEGRATED PERIPHERALS ROM PCI/ISA BIOS(2A5LEPA9) INTEGRATED PERIPHERALS WARD SOFTWARE, INC. Onboard Primary PCI IDE : Enabled Onboard Parallel Port : 378/IRQ7 Onboard Secondary PCI IDE : Enabled Onboard Parallel Mode : ECP / EPP IDE Prefetch Mode : Enabled ECP Mode Use DMA IDE HDD Block Mode...
  • Page 28 AWARD BIOS 3-15 IDE Primary Master PIO: The default value is Auto. Auto : BIOS will automatically detect the Onboard Primary Master PCI IDE HDD Accessing mode. Mode0~4 : Manually set the IDE Accessing mode. IDE Primary Slave PIO: The default value is Auto. Auto : BIOS will automatically detect the Onboard Primary Slave PCI IDE HDD Accessing mode.

  • Page 29: Load Setup Defaults

    3-16 CHAPTER 3 Onboard UART 2 Mode:The default value is standard. This field allows the User to select the COM2 port that can support a serial Infrared Interface. Standard: Support a Serial Infrared Interface IrDA. HPSIR: Support a HP Serial Infrared Interface format. ASKIR: Support a Sharp Serial Infrared Interface format.

  • Page 30: Change Supervisor Or User Password

    AWARD BIOS 3-17 ROM PCI/ISA BIOS(2A5LEPA9) CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP SUPERVISOR PASSWORD BIOS FEATURES SETUP USER PASSWORD CHIPSET FEATURES SETUP IDE HDD AUTO DETECTION POWER MANAGEMENT SETUP HDD LOW LEVEL FORMAT PNP/PCI CONFIGURA ETUP Load SETUP Default (Y/N)? INTEGRATED PERIPH SAVING LOAD SETUP DEFAULTS...

  • Page 31: Ide Hdd Auto Detection

    3-18 CHAPTER 3 3-9 IDE HDD AUTO DETECTION The "IDE HDD AUTO DETECTION" utility is a very useful tool especially when you do not know which kind of hard disk type you are using. You can use this utility to detect the correct disk type installed in the system automatically.
  • Page 32 AWARD BIOS 3-19 LBA (Logical Block Addressing) mode: This is a new HDD accessing method to overcome the 528 Megabyte bottleneck. The number of cylinders, heads and sectors shown in the setup may not be the number physically contained in the HDD. During the HDD accessing, the IDE controller will transform the logical address described by sector, head and cylinder into its own physical address inside the HDD.

  • Page 33: Hdd Low Level Format

    3-20 CHAPTER 3 Note: To support LBA or LARGE mode of HDDs, there must be some softwares involved. All softwares are located in the Award HDD Service Routine (1NT 13h). It may fail to access a HDD with LBA (LARGE) mode selected if you are running under on Operating System which replaces the whole 1NT 13h.

  • Page 34: I/O & Memory Map

    TECHNICAL INFORMATION 4-1 Chapter 4 Technical Information 4-1 I/O & MEMORY MAP MEMORY MAP Address Range Size Description [00000-7FFFF] 512K Conventional memory [80000-9FBFF] 127K Extended Conventional memory [9FC00-9FFFF] Extended BIOS data area if PS/2 mouse is installed [A0000-C7FFF] 160K Available for Hi DOS memory [C8000-DFFFF] Available for Hi DOS memory and adapter ROMs [E0000-EEFFF]...

  • Page 35: Time & Dma Channels Map

    4-2 CHAPTER 4 4-2 TIME & DMA CHANNELS MAP TIME MAP: TIMER Channel 0 System timer interrupt. TIMER Channel 1 DRAM REFRESH request. TIMER Channel 2 SPEAKER tone generator. DMA CHANNELS : DMA Channel 0 Available. DMA Channel 1 Onboard ECP (Option). DMA Channel 2 FLOPPY DISK (SMC CHIP).

  • Page 36: Rtc & Cmos Ram Map

    TECHNICAL INFORMATION 4-3 4-4 RTC & CMOS RAM MAP RTC & CMOS : Seconds. Second alarm. Minutes. Minutes alarm. Hours. Hours alarm. Day of week. Day of month. Month. Year. Status register A. Status register B. Status register C. Status register D. Diagnostic status byte.

  • Page 37: Appendix A: Post Codes

    4-4 CHAPTER 4 APPENDIX A: POST CODES ISA POST codes are typically output to port address 80h. POST(hex) DESCRIPTION 01-02 Reserved. Turn off OEM specific cache, shadow. 1.Initialize EISA registers (EISA BIOS only). 2.Initialize all the standard devices with default values Standard devices includes. -DMA controller (8237).
  • Page 38 TECHNICAL INFORMATION 4-5 POST(hex) DESCRIPTION Initialization of the BIOS Data Area. (40:ON - 40:FF) 1.Program some of the Chipset's value according to Setup. (Early Setup Value Program) 2.Measure CPU speed for display & decide the system clock speed. 3.Video initialization including Monochromc, CGA, EGA/VGA. If no display device found, the speaker will beep.
  • Page 39 4-6 CHAPTER 4 POST(hex) DESCRIPTION 1.Display the Award Plug & Play BIOS Extension message. (PnP BIOS only) 2.Program all onboard super I/O chips (if any) including COM ports, LPT ports, FDD port ... according to setup value. 33-3B Reserved. Set flag to allow users to enter CMOS Setup Utility. 1.Initialize Keyboard.
  • Page 40 TECHNICAL INFORMATION 4-7 POST(hex) DESCRIPTION 1.Initialize all ISA ROMs. 2.Later PCI initializations. (PCI BIOS only) -assign IRQ to PCI devices. -initialize all PCI ROMs. 3.PnP Initialzations. (PnP BIOS only) -assign IO, Memory, IRQ & DMA to PnP ISA devices. -initialize all PnP ISA ROMs. 4.Program shadows RAM according to Setup settings.

  • Page 41: Appendix B: I/O Connector

    4-8 CHAPTER 4 APPENDIX B: I/O CONNECTORS J1 : PS/2 MOUSE CONNECTOR: 1. DATA 2. CLK 3. GND 4. NC 5. VCC CN1 : USB CONNECTOR: Signal Name Signal Name Ground USB_VCC Ground USB_data0- Ground USB_data0+ Ground Ground Ground USB_VCC Ground USB_data1- Ground...
  • Page 42 TECHNICAL INFORMATION 4-9 FDD1 : Floppy Disk Connector Signal Name Signal Name Ground FDHDIN Ground Reserved Ground FDEDIN Ground Index- Ground Motor Enable Ground Drive Select B- Ground Drive Select A- Ground Motor Enable Ground DIR- Ground STEP- Ground Write Data Ground Write Gate Ground...

  • Page 43: System Requirements

    4-10 CHAPTER 4 Appendix C : AGP Driver for Windows 95 Installation Guide This section provides the information for installation of Apollo VP3 VxD Driver which supports Accelerated Graphics Port (AGP) functionalities. SYSTEM REQUIREMENTS 1.Microsoft Windows 95 OSR2.1 (OSR2.0 with USB upgrade) 2.VIA Apollo VP3 AGP Driver (Vgart.VXD) 3.AGP VGA Card with Driver 4.Direct X5 DDk or SDK...
  • Page 44 TECHNICAL INFORMATION 4-11 b. Click on "Direct X" then c. Click on "Direct Draw" and d. Check if there are some values existing in the "Bit" and "overlays." if there is, that means the AGP can be activated properly. REPLACING AN EXISTING VGA CARD WITH THE AGP VGA CARD 1.
