1.3.5 Power-On/Off (Remote)
The board has a single 20-pins connector for ATX power supplies. For
ATX power supplies that support the Remote On/Off feature, this should be
connected to the systems front panel for system Power On/Off button. The
systems power On/Off button should be a momentary button that is normally
open.
The board has been designed with "Soft Off" functions. You can turn Off
the system from one of two sources: The first is the front panel Power
On/Off the button, and the other is the "Soft Off" function (coming from the
M/B onboard circuit controller) that can be controlled by the operating
system.
1.3.6 IP-4PCI2E Series Overview
Function / Model
Chipset
Gigabit Ethernet function
Audio function
Two EIDE interface
One Floppy interface
One Parallel port
AGP8X slot
PCI-X slots
PCI slots
ISA slots
Serial ports
S-ATA ports
USB 2.0 ports
Fan connectors
External KB/MS connector
2(one shared with PCI-X)
5
Introduction
IP-4PCI2E
®
Intel 875P
1
2
2
2
2
4
3
