PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
M6 x 50mm Bolt (23)
M8 x 55mm Carriage Bolt (24)
M10 x 67mm Bolt (31)
M10 x 80mm Bolt (27)
M10 x 100mm Bolt (30)
M10 x 140mm Bolt (35)
M10 Nylon Locknut (33)
M10 Washer (32)
M8 Nylon Locknut (25)
M6 Washer (34)
M6 x 16mm Bolt (26)
12.5mm Spacer (15)
REMOVE THIS PART IDENTIFICATION CHART
PART LIST/EXPLODED DRAWING
SAVE THIS PART IDENTIFICATION CHART
PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE
