- Page 1 MS1071T0TX-ESPRESSO FINISH MS1072T0TX-WHITE FINISH MS1068T0TX-BLACK SLIDING-DOOR WINDOW-PANE For assistance with assembly contact: Southern Enterprises Inc. MEDIA CABINET Customer Service 1-800-633-5096 Assembly Instruction service@seidal.com www.seidal.com...
- Page 2 MS1071T0TX-ESPRESSO FINISH/MS1072T0TX-WHITE FINISH MS1068T0TX-BLACK SLIDING-DOOR WINDOW-PANE MEDIA CABINET Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 MS1071T0TX-ESPRESSO FINISH MS1072T0TX-WHITE FINISH MS1068T0TX-BLACK SLIDING-DOOR WINDOW-PANE MEDIA CABINET Assembly Instruction Step 1: PLEASE DO NOT OVER-TIGHTEN CAMBOLTS. PLEASE STOP WHEN YOU FEEL TIGHT PUT ALL PARTS ON A SOFT SURFACE TO PREVENT SCRATCHES. PLACE LEFT SIDE PANEL (B) SMOOTH SIDE ON FLAT SURFACE, THEN SCREW 2 CAM-BOLTS (3) INTO PRETHREADED INSERT HOLES ON SIDE PANEL (B) UNTIL STOP.
- Page 4 Step 2: ATTACH LEFT AND RIGHT BACK PANELS (H, G) INTO SLOTS OF PARTS (A, B, C, D). INSERT PAN HEAD WOOD SCREWS (7) THROUGH PREDRILLED HOLES ON LEFT AND RIGHT BACK PANELS (G, H) AND TIGHTEN INTO REAR EDGES OF PARTS (A, B, C, D, E).
- Page 5 Step 4: FIT LEFT AND RIGHT DOORS (I, J) INTO GROOVES ON TOP PANEL AND BASE (A, D). AS SHOWN IN FIGURE AFTER LOCKING THE DOORS,IF THE GAP BETWEEN SIDE PANEL(S) AND DOOR IS UNEVEN,YOU CAN ADJUST THE SCREWS ON TWO CASTERS ON THE BOTTOM OF DOORS TO GET EVEN GAP. ( I ) FIGURE 4...
- Page 6 Extra hardware may be included. If any items are missing, please contact Southern Enterprises at 800-633-5096 or in Dallas (972) 869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues with your purchase. Please ask for a customer service representative for issues involving damages or replacement parts.
