- Page 1 MS663200TX Heyburn Industrial TV/Media Stand For assistance with assembly, contact: Southern Enterprises, Inc. Assembly Instructions Customer Service: 1-800-633-5096 service@seidal.com www.seidal.com PO#：13499 Page | 1...
- Page 2 Heyburn Industrial TV/Media Stand Parts List Please check packaging for all parts and hardware before discarding. Before beginning assembly, separate each type of hardware. Carefully study the diagrams below and check that you have all parts indicated. Call Customer Service if missing hardware. Using the incorrect hardware will cause damage. Quantity Quantity Quantity...
- Page 3 Quantity Quantity Quantity of 2 of 4 of 31 Magnets Round Wood Screws ∅3×12mm Round Wood Screws ∅3×15mm Quantity Quantity Quantity of 8 of 8 of 8 Wood Dowels Flat Wood Screws Shelf Pins ∅8×30 ∅3×13mm Quantity Quantity Quantity of 2 of 4 of 4 Knobs...
- Page 4 Heyburn Industrial TV/Media Stand Assembly Instructions Start screwing with fingers to help align Cam-Bolts. Insert Cam-Locks (2) into holes on Vertical Panel (D). Screw Cam-Bolts (1) and insert Wood Dowels (7) into holes on Fixed Shelf (B) and Bottom Panel (C). Attach Vertical Panel (D) to Bottom Panel (C) and Fixed Shelf (B).
- Page 5 Insert Cam-Locks (2) into holes on assembled unit. Screw Cam-Bolts (1) and insert Wood Dowels (7) into holes on Top Panel (A). Attach Top Panel (A) to assembled unit. Tighten by rotating Cam-Locks (2) clockwise with Phillips screwdriver. Cover Cam-Locks (2) with Cam-Covers (3). Figure 3 Attach Upper Back Panel (G) and Lower Back Panel (H) to back of assembled unit...
- Page 6 Start with fingers to help align screws before using screwdriver. Attach Magnet (4) to assembled unit with Round Head Screws (5). Attach Left Door (I) and Right Door (J) to assembled unit with Screws (8). Insert Shelf Pins (9) into holes on unit. Attach Knobs (10) through Left Door (I) and Right Door (J) with Bolts (11).
- Page 7 Mark two desired locations on wall for each Bracket (12), same distance as Brackets (12) attached to back of unit. Drill two 3/16" holes on wall for each Bracket (12). Insert Plastic Anchors (15) into holes on wall (use a hammer to help you). Attach Brackets (12) to wall using Screws (13).
-
Page 8: Parts Replacement Form
For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts. - Page 9 DO NOT EXCEED RECOMMENDED LOAD. Use with products heavier than the maximum sizes and weights indicated may result in instability causing possible injury. This unit contains a permanent warning sticker located on back panel. Model: MS663200TX Heyburn Industrial TV/Media Stand Southern Enterprises, Inc.
