2. Extract the files in the .zip file to a folder on your computer.
3. If you use the flash cable RS232/DMX, connect a serial port of your computer with DMX input of the fixture
by means of this cable.
If you use the Robe Universal Interface, connect a USB port of your computer with the Robe Universal Interface
by means of the USB cable and DMX input of the fixture with the DMX output of the Robe Universal Interface
via a DMX cable.
4. Disconnect the fixture from the other fixtures in a DMX chain. Make sure the lamp is switched off.
5. Switch the fixture to the updating mode.
Note: If you do not want to continue in the software update, you have to switch off and on the fixture
to escape from the updating mode.
We recommend to cancel all running programs on your computer before starting the Software Uploader.
6. Double-click the software uploader file (for example, " DSU_RobinMegapointe_17033149.exe") in the
extracted files. The Software Uploader program will start.
7. Select desired port and then click on the "Connect" button. (Select desired "COM "if serial port of your PC is
used or "Robe Universal Interface" if the Robe Universal Interface is used).
If the connection is OK, click the "Start Uploading" button to start software uploading. It will take several
minutes to perform software update.
If the option "Incremental Update" is not checked, all processors will be updated (including
processors with the same software version).
If you wish to update only later versions of processors, check the "Incremental Update box".
Avoid interrupting the process. Update status is being displayed in the "Info Box" window.
When the update is finished, the line with the text "The fixture is successfully updated" will appear in
this window and the fixture will reset with the new software.
Note: : In case upload process is interrupted (e.g. power loss), the fixture stays in "Updating mode" and you will
have to repeat the software update again.

6.7 Icon "Lamp menu"

Lamp Status - The item enables to switch the lamp on/off.
Settings - The menu offers many items for setting of lamp behaviour.
Lamp Power - The item allows to set desired power of the lamp
Eco mode - Lamp power is reduced to 380W, lamp life is extended to 2000 hrs.
Standard mode - Lamp runs on max. power of 470W. Lamp life is 1500hrs. This mode is set as
default.
This setting can be temporarily changed by DMX command at "Power/Special functions" channel
Lamp Ignition Delay - The item allows to set the time delay( 0-90sec.) before igniting the lamp by DMX
command. If the lamp is started directly from the control panel, the time delay will be ignored.
Lamp Light Sensor - Select this item to switch the light sensor off. The option "On" is intended for a standard
operation. The option "Off" is for "emergency operation" only! If the lamp light sensor is switched off, the fixture
will still try to ignite the lamp (even when the lamp is damaged or absent), on this account some electronics
parts of the fixture can be damaged!
Lamp On/Off Settings - Use the menu to set rules for automatic switching on/off the lamp.
Lamp On Power On - If the item is on, the lamp will be automatically turn on after switching the
fixture on.
Lamp Off via DMX - The item enables to switch the lamp off via DMX command from DMX
controller.
Lamp On if DMX Present - The item allows you to strike the lamp automatically after 26 seconds
if DMX signal is present on the fixture´s DMX input.
Lamp Off if not DMX - The item allows you to switch off the lamp automatically after 2 minutes
if DMX signal is missing on the fixture´s DMX input.
31
