USER'S
MANUAL
POS-3520
POS-3520
15" POS System Powered by
Intel
M6
®
Atom
®
D525 Platform

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POS-3520 and is the answer not in the manual?

Questions and answers

Related Manuals for protech POS-3520

Summary of Contents for protech POS-3520

  • Page 1 USER’S MANUAL POS-3520 15” POS System Powered by Intel ® Atom ® D525 Platform POS-3520...
  • Page 2 POS-3520 POS System With LCD / Touchscreen COPYRIGHT NOTICE This user’s manual is meant to assist users in installing and setting up the system. The information contained in this document is subject to change without any notice. This manual is copyrighted May 2011 (Revised Edition: July 2012). You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............POS System Illustration ..........System Specification ............. Safety Precautions ............CHAPTER 2 SYSTEM CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ........... How to Set the Jumpers ..........COM Port &...
  • Page 5 Exploded Diagram for Fingerprint Module …………………. Exploded Diagram for POS-3520 Hard Disk Drive Remove/ A-10 Install ……………………………………………………….. Exploded Diagram for POS-3520 LCD Panel Remove/ Install .. A-13 Exploded Diagram for POS-3520 Mini-PCIE Installation .…. A-15 Exploded Diagram for POS-3520 Motherboard ..……………...
  • Page 6 Contents APPENDIX B TECHNICAL SUMMARY Block Diagram ................. Interrupt Map ................DMA Channels Map ..............I/O Map ..................Watchdog Timer Configuration ……………………………… Flash BIOS Update ………………………………………….. B-10...
  • Page 7 CHAPTER INTRODUCTION This chapter gives you the information for POS-3520. It also outlines the system specifications. Sections included: About This Manual POS System Illustration System Specifications Safety Precautions Experienced users can jump to chapter 2 on page 2-1 for a quick start.

  • Page 8: Appendix B Technical Summary

    Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our POS-3520 system. The POS-3520 is an updated system designed to be comparable with the highest performance of IBM AT personal computers. The POS-3520 provides faster processing speed, greater expandability and can handle more tasks than before.

  • Page 9: Pos System Illustration

    Chapter 1 Introduction 1-2. POS SYSTEM ILLUSTRATION Front View Rear View Side View Bottom View Quarter View ′ Page: 1-3 POS-3520 USER S MANUAL...

  • Page 10: System Specification

    PS/2 Mouse, with mini DIN connecter on rear panel Serial Port: 3 x DB-9 & 1 x RJ45, +5V/ 12V selectable Universal Serial BUS Port: 5 x USB ports LAN Function: 1 x 10/100/1000 Mbps Audio Function: 1 x 2W Speaker Page: 1-4 ′ POS-3520 USER S MANUAL...
  • Page 11 Read only, output through PS/2 KB interface MSR (Optional): JIS-I or II, ISO Tracker 1+2+3 (PS/2 KB Interface) Wireless LAN (Optional): Mini PCIe Wireless LAN Module (802.11b/g/n, 1T1R) Fingerprint (Optional): Embedded Fingerprint module (USB interface) ′ Page: 1-5 POS-3520 USER S MANUAL...

  • Page 12: Safety Precautions

    Avoid exposure to sunlight for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use the POS-3520 when it has been left outdoors in a cold winter day.
  • Page 13 If heavy stains are present, moisten a cloth with diluted neutral washing agent or alcohol and then wipe thoroughly with a dry cloth. d. If dust is accumulated on the case surface, remove it by using a special vacuum cleaner for computers. ′ Page: 1-7 POS-3520 USER S MANUAL...
  • Page 14 CHAPTER SYSTEM CONFIGURATION Helpful information that describes the jumper and connector settings, and component locations. Sections included: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector Pin Assignments Page 2-1...

  • Page 15: Jumper & Connector Quick Reference Table

    LVDS Connector LVDS1, LVDS2 2-21 SATA Connector SATA1 2-23 SATA Power Connector JPWR_4P1 2-23 Touch Panel Connector TOUCH1 2-24 Touch Panel Selection JP16 2-24 Clear CMOS Data Selection 2-25 Compact Flash Connector 2-26 Page: 2-2 ’ POS-3520 USER S MANUAL...

  • Page 16: Component Locations

    Chapter 2 System Configuration 2-2. COMPONENT LOCATIONS 72 71 COM3 PWR_IN1 POS-3520 Connector, Jumper and Component locations Page: 2-3 ’ POS-3520 USER S MANUAL...

  • Page 17: How To Set The Jumpers

    PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. Page: 2-4 ’ POS-3520 USER S MANUAL...
  • Page 18 Chapter 2 System Configuration JUMPER DIAGRAMS JUMPER SETTINGS Page: 2-5 ’ POS-3520 USER S MANUAL...

  • Page 19: Com Port & Vga Connector

    DSR2 RTS2 CTS2 RI / +5V / +12V selectable COM3: COM3 Connector The pin assignments are as follows: ASSIGNMENT DCD3 RXD3 TXD3 COM3 DTR3 DSR3 RTS3 CTS3 RI / +5V / +12V selectable Page: 2-6 ’ POS-3520 USER S MANUAL...
  • Page 20 RTS4 CTS4 RI / +5V / +12V selectable COM2-1: COM2 External Connector The pin assignments are as follows: ASSIGNMENT COM2_1 DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 RI / +5V / +12V selectable Page: 2-7 ’ POS-3520 USER S MANUAL...
  • Page 21 TXD1 DTR1 DSR1 RTS1 CTS1 RI / +5V / +12V selectable All COM port is selectable for RI, +5V or +12V. For more information, please refer to our “COM RI and Voltage Selection”. Page: 2-8 ’ POS-3520 USER S MANUAL...

  • Page 22: Com Port Ri And Voltage Selection

    “12V” for three COM ports or above; otherwise, the system may shut down due to power deficiency. JP_COM1: COM1 RI & Voltage Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION VCC12 ***Manufacturing Default – RI Page: 2-9 ’ POS-3520 USER S MANUAL...
  • Page 23 Chapter 2 System Configuration JP_COM2: COM2 RI & Voltage Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION VCC12 ***Manufacturing Default – RI Page: 2-10 ’ POS-3520 USER S MANUAL...
  • Page 24 Chapter 2 System Configuration JP_COM3: COM3 RI & Voltage Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION VCC12 ***Manufacturing Default – RI Page: 2-11 ’ POS-3520 USER S MANUAL...
  • Page 25 Chapter 2 System Configuration JP_COM4: COM4 RI & Voltage Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION VCC12 ***Manufacturing Default – RI Page: 2-12 ’ POS-3520 USER S MANUAL...

  • Page 26: Mini-Din And Usb Connector

    The pin assignments are as follows: ASSIGNMENT USB2+ USB2- VCC5 USB3+ USB3- VCC5 KDAT JPS2USB1 MDAT V5SB KCLK MCLK USB5: Internal USB Ports Connector The pin assignments are as follows: ASSIGNMENT USB5- USB5+ VCC5 Page: 2-13 ’ POS-3520 USER S MANUAL...

  • Page 27: Lan & Usb Connector

    2-7. LAN & USB CONNECTOR JRJ45USB1: LAN & USB Connector The pin assignments are as follows: Green Orange ASSIGNMENT LAN1_MDIP0 LAN1_MDIN0 LAN1_MDIP1 LAN1_MDIN1 LAN1_MDIP2 LAN1_MDIN2 LAN1_MDIP3 LAN1_MDIN3 JRJ45USB1 ASSIGNMENT VCC5 USB0- USB0+ VCC5 USB1- USB1+ Page: 2-14 ’ POS-3520 USER S MANUAL...

  • Page 28: Cash Drawer Connector

    Write "0"h to I/O space register "50C"h Bit 6 To Close Drawer2 Write "1"h to I/O space register "50C"h Bit 6 Detect Drawer2 Status Read I/O space register "538"h (GPIO 37) Definition (bit5) Page: 2-15 ’ POS-3520 USER S MANUAL...

  • Page 29: Cash Drawer Power Selection

    Chapter 2 System Configuration 2-9. CASH DRAWER POWER SELECTION JP14, JP17: Cash Drawer Power Selection The jumper settings are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION +12V +24V (default) *** Manufactory default – +24V Page: 2-16 ’ POS-3520 USER S MANUAL...

  • Page 30: Power Led Connector

    2-11. SMART FAN CONNECTOR FAN2: CPU Smart Fan Connector The pin assignments are as follows: ASSIGNMENT CPUFANIN CPUFANOUT 2-12. POWER CONNECTOR FAN1: Provide 12 Voltage Connector The pin assignments are as follows: ASSIGNMENT VCC12 Page: 2-17 ’ POS-3520 USER S MANUAL...

  • Page 31: Reset Switch Connector

    2-14. POWER FOR THERMAL PRINTER CONNECTOR PRT_PWR1: Power for Thermal printer Connector The pin assignments are as follows: ASSIGNMENT VCC24SB VCC24SB 2-15. EXTERNAL SPEAKER CONNECTOR SPK1: External Speaker Connector The pin assignments are as follows: ASSIGNMENT SPK_GND SPK_OUT Page: 2-18 ’ POS-3520 USER S MANUAL...

  • Page 32: Inverter Connector

    Chapter 2 System Configuration 2-16. INVERTER CONNECTOR INV1: Inverter Connector The pin assignments are as follows: ASSIGNMENT +12V +12V LVDS_BKLTEN BRCTR INV2: Inverter Connector The pin assignments are as follows: ASSIGNMENT +12V LVDS_BKLTEN BRCTR Page: 2-19 ’ POS-3520 USER S MANUAL...

  • Page 33: Msr/ Card Reader Connector

    KB_DATA_C (Input) KB_DATA (Output) 2-18. PRINTER CONNECTOR LPT1: LPT Connector. The assignments are as follows: ASSIGNMENT ASSIGNMENT STBJ ALFJ PDR0 ERRJ PDR1 PAR_INITJ PDR2 SLCTINJ PDR3 PDR4 PDR5 PDR6 PDR7 ACKJ BUSY SLCTJ Page: 2-20 ’ POS-3520 USER S MANUAL...

  • Page 34: Lvds Connector

    Chapter 2 System Configuration 2-19. LVDS CONNECTOR LVDS1: LVDS Connector. The pin assignments are as follows: ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS_YAP2 LVDS_VCC LVDS_YAM2 LVDS_YAP1 LVDS_CLKAP LVDS_YAM1 LVDS_CLKAM LVDS_YAP0 LVDS_YAM0 LVDS_VCC LVDS_VCC Page: 2-21 ’ POS-3520 USER S MANUAL...
  • Page 35 Chapter 2 System Configuration LVDS2: LVDS Connector. The pin assignments are as follows: ASSIGNMENT ASSIGNMENT LVDS_VCC CLKO+ CLKO- RINO2+ RINO2- RINO1+ RINO1- RINO0+ RINO0- LVDS_VCC LVDS_VCC Page: 2-22 ’ POS-3520 USER S MANUAL...

  • Page 36: Sata Connector

    Chapter 2 System Configuration 2-20. SATA CONNECTOR SATA1: Serial ATA Connector The pin assignments are as follows: ASSIGNMENT 2-21. SATA POWER CONNECTOR JPWR_4P1: Serial ATA Connector The pin assignments are as follows: ASSIGNMENT VCC12 Page: 2-23 ’ POS-3520 USER S MANUAL...

  • Page 37: Touch Panel Connector

    LL (Low Left) Probe UR (Up Right) UL (Up Left) 2-23. TOUCH PANEL SELECTION JP16: Touch Panel Selection The selections are as follows: JUMPER JUMPER SELECTION SETTINGS ILLUSTRATION e-Turbo *** Manufactory default – Elo Page: 2-24 ’ POS-3520 USER S MANUAL...

  • Page 38: Clear Cmos Data Selection

    To clear CMOS data, user must power-off the computer and set the jumper to “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. Page: 2-25 ’ POS-3520 USER S MANUAL...

  • Page 39: Compact Flash Connector

    Chapter 2 System Configuration 2-25. COMPACT FLASH CONNECTOR CF1: Compact Flash Connector The pin assignments are as follows: ASSIGNMENT ASSIGNMENT CSJ1 CSJ3 SDIORDJ SDIOWRJ IRQ14 -CSEL RESETJ IORDJ ACKJ CF_LEDJ -PDIAG Page: 2-26 ’ POS-3520 USER S MANUAL...

  • Page 40: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter provides the detailed information users need to install driver utilities for the system. Sections included: ® Intel Chipset Software Installation Utility VGA Driver Utility LAN Driver Utility Sound Driver Utility Touch Screen Driver Utility Wireless Driver Utility (Optional) Page: 3-1...

  • Page 41: Introduction

    Chapter 3 Software Utilities 3-1. INTRODUCTION Enclosed with the POS-3520 Series package is our driver utilities, which comes in a CD ROM format. Refer to the following table for driver locations. Filename Purpose (Assume that CD ROM drive is D:)

  • Page 42: Intel Chipset Software Installation Utility

    The utility pack is to be installed only for Windows XP/ 7 series, and it should be installed right after the OS installation. Please follow the steps below: Connect the USB-CD ROM device to the POS-3520 and insert the driver disk inside. Enter the “Main Chip” folder where the Chipset driver is located (depending on your OS platform).

  • Page 43: Vga Driver Utility

    Chapter 3 Software Utilities 3-3. VGA DRIVER UTILITY The VGA interface embedded with the POS-3520 series can support a wide range of display types. You can have dual displays via CRT and LVDS interfaces work simultaneously. 1. Win XP Series 2.

  • Page 44: Lan Driver Utility

    Chapter 3 Software Utilities 3-4. LAN DRIVER UTILITY The POS-3520 Series is enhanced with LAN function that can support various network adapters. Installation platform for the LAN driver is listed as follows: 1. Win XP Series 2. Win 7 Series For more details on the Installation procedure, please refer to the Readme.txt file found on LAN Driver Utility.

  • Page 45: Sound Driver Utility

    3-5-1. Installation of Sound Driver To install the Sound Driver, refer to the readme.txt file on the driver disc (:\Sound\Realtek\Readme.txt). Connect the USB-CD ROM device to the POS-3520 and insert the driver disk inside. Enter the “Sound” folder where the Sound driver is located (depending on your OS platform).

  • Page 46: Touchscreen Driver Utility

    2. Win 7 Series 3-6-1. Installation of Touchscreen Driver To install the Touchscreen Driver, follow the steps below: Connect the USB-CD ROM device to the POS-3520 and insert the driver disk inside. Enter the “Device\Touchscreen” folder where the Touchscreen driver is located.

  • Page 47: Wireless Driver Utility (Optional)

    2. Win 7 Series 3-7-1. Installation of Wireless Driver To install the Wireless Driver, follow the steps below: Connect the USB-CD ROM device to the POS-3520 and insert the driver disk inside. Enter the “Device\Embedded Wireless Module” folder where the Wireless driver is located.

  • Page 48: Introduction

    CHAPTER BIOS SETUP This chapter shows how to configure the AMI BIOS settings. Sections included: Introduction Entering Setup Main Advanced Boot Security Chipset Exit Page: 4-1...
  • Page 49 This chapter will show you the function of the BIOS (Basic Input and Output System) in managing the features of your system. The POS-3520 POS Terminal is equipped with the BIOS from AMI (American Megatrends Inc). The following pages describe how to use the BIOS for configure system hardware by BIOS Setup menu.
  • Page 50 BIOS setup program. In a moment, the main menu of the AMI SETUP program will be shown on the screen: ′ Page: 4-3 POS-3520 USER S MANUAL...
  • Page 51 You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. Page: 4-4 ′ POS-3520 USER S MANUAL...
  • Page 52 System Time This setting allows you to set the system time. The format is [Hour: Minute: Second]. User can directly key-in value or use <+> or <-> arrow keys to increase/decrease it. ′ Page: 4-5 POS-3520 USER S MANUAL...
  • Page 53 Enter Go to Sub Screen General Help F10 Save and Exit ESC Exit v02.68 (c)Copyright 1985-2009 American Megatrends, Inc. Advanced Screen This menu provides advanced configurations such as CPU Configuration, IDE Configuration, SuperIO Configuration…etc. Page: 4-6 ′ POS-3520 USER S MANUAL...
  • Page 54 CPUs. Enable this function will improve parallelization of computation performed on PC microprocessor. For each processor core that is physically present, the operation system addresses two virtual processors, and shares the workload between them when possible. ′ Page: 4-7 POS-3520 USER S MANUAL...
  • Page 55 This menu provides advanced IDE configuration for hard drive. The control items of SATA 1 / CF Card are all the same and describe in next section. SATA 1/ CF Card This setting displays the status of storages. Page: 4-8 ′ POS-3520 USER S MANUAL...
  • Page 56 LBA/Large Mode Enabling LBA causes Logical Block Addressing to be used in place of Cylinders, Heads and Sectors. Block (Multi-Sector Transfer) Any selection except Disabled determines the number of sectors transferred per block. ′ Page: 4-9 POS-3520 USER S MANUAL...
  • Page 57 This gives you an opportunity to move data from a hard disk that is going to fail to a safe place before the hard disk becomes offline. 32Bit Data Transfer Enables/Disable 32-bit data transfer. Page: 4-10 ′ POS-3520 USER S MANUAL...
  • Page 58 Select IO address as serial ports default resource. Serial Port1~4 IRQ Select IO IRQ as serial ports default resource. Parallel Port Address Select IO address for parallel ports resource allocation. Parallel Port Mode Select the operation mode for parallel port. ′ Page: 4-11 POS-3520 USER S MANUAL...
  • Page 59 System Temperature / CPU Temperature Both section show System and CPU current temperature. CPUFAN Speed This item shows CPU fan speed. VCORE / 12V / 5V / 1.05V /VSB These items provide hardware health information. Page: 4-12 ′ POS-3520 USER S MANUAL...
  • Page 60 Once a power failure situation happens, this item decides the system power state after AC power restore back. Resume On RTC Alarm When user set this option to [Enable], it allows system to be wake up at specific date/time. ′ Page: 4-13 POS-3520 USER S MANUAL...
  • Page 61 (c)Copyright 1985-2009 American Megatrends, Inc. USB Configuration Screen Legacy USB Support Set to [Enabled] if you want to use USB device in the legacy operating system, such as MS-DOS or SCO Unix. Page: 4-14 ′ POS-3520 USER S MANUAL...
  • Page 62 Select which type of device that USB mass storage emulation. When user select to [Auto], the USB storage size less than 530MB will be emulated as floppy drive and remaining as hard drive. ′ Page: 4-15 POS-3520 USER S MANUAL...
  • Page 63 ESC Exit v02.68 (c)Copyright 1985-2009 American Megatrends, Inc. Boot Screen This menu provides control items for system boot configuration. PXE Support This is the main control item for enable/disable PXE (Preboot Execution Environment) support. Page: 4-16 ′ POS-3520 USER S MANUAL...
  • Page 64 Enable this item allows BIOS POST to skip some tests during boot-up for saving boot time. Quiet Boot When set this option to [disabled], BIOS will display normal POST messages. Parity Check This setting enables or disables memory or parity error check. ′ Page: 4-17 POS-3520 USER S MANUAL...
  • Page 65 Select Screen Select Item Change Option General Help F10 Save and Exit ESC Exit v02.68 (c)Copyright 1985-2009 American Megatrends, Inc. Boot Device Priority Screen …Boot Device Choose the boot sequence from the available devices.. Page: 4-18 ′ POS-3520 USER S MANUAL...
  • Page 66 USB storages. Press <Enter> to enter the sub-menu and press < ↑ > or < ↓ > arrow keys to select the device. Another way is to press <+> or <-> to move it up/down in the priority list. ′ Page: 4-19 POS-3520 USER S MANUAL...

  • Page 67: Security Settings

    Change User Password User Password controls system access right when power on. These settings allow user to set or change the user password. Page: 4-20 ′ POS-3520 USER S MANUAL...

  • Page 68: Chipset

    North Bridge Configuration South Bridge Configuration Select Screen Select Item Enter Go to Sub Screen General Help F10 Save and Exit ESC Exit v02.68 (c)Copyright 1985-2009 American Megatrends, Inc. Advanced Chipset Settings Screen ′ Page: 4-21 POS-3520 USER S MANUAL...
  • Page 69 Security Chipset ExitM North Bridge Chipset Configuration Video Function Configuration Select Screen Select Item Change Option General Help F10 Save and Exit ESC Exit v02.68 (c)Copyright 1985-2009 American Megatrends, Inc. North Bridge Chipset Configuration Page: 4-22 ′ POS-3520 USER S MANUAL...
  • Page 70 Setting it to DVMT Mode ensures that system memory is dynamically allocated for optimal balance between graphics and system performance. Boot Display Device Choose the default boot display device by user requirement such as [CRT], [LVDS] and [CRT+LVDS] ′ Page: 4-23 POS-3520 USER S MANUAL...
  • Page 71 ESC: Exit v02.68 (c)Copyright 1985-2009 American Megatrends, Inc. South Bridge Chipset Configuration Screen USB 2.0 Controller Enable or disable the USB 2.0 Controller. HDA Controller Enable or disable the onboard High-definition Audio controller. Page: 4-24 ′ POS-3520 USER S MANUAL...

  • Page 72: Exit

    Abandon all changes and exit the BIOS setup screen. User can also press the [ESC] key for this operation. Discard Changes Discard all changes done so far to the setup items. User can press the [F7] key for this operation. ′ Page: 4-25 POS-3520 USER S MANUAL...
  • Page 73 Press <Enter> on this item, it will show a confirmation dialog box with a message like below: To use the BIOS failsafe default values, change the prompt to "Ok" and press the <Enter > key. User can also press the [F8] key for this operation. Page: 4-26 ′ POS-3520 USER S MANUAL...

  • Page 74: Appendix A System Assembly

     Exploded Diagram for MSR & Fingerprint Remove/ Install  Exploded Diagram for Fingerprint Module  Exploded Diagram for POS-3520 Hard Disk Drive Remove/ Install  Exploded Diagram for POS-3520 LCD Panel Remove/ Install  Exploded Diagram for POS-3520 Mini-PCIE Installation ...

  • Page 75: Exploded Diagram For 2 Inch Thermal Printer Remove/ Install

    Appendix A System Assembly EXPLODED DIAGRAM FOR 2 INCH THERMAL PRINTER REMOVE/ INSTALL  Page: A-2 POS-3520 USER S MANUAL...
  • Page 76 Appendix A System Assembly  Page: A-3 POS-3520 USER S MANUAL...
  • Page 77 Appendix A System Assembly  Page: A-4 POS-3520 USER S MANUAL...

  • Page 78: Exploded Diagram For 3 Inch Thermal Printer Remove/ Install

    Appendix A System Assembly EXPLODED DIAGRAM FOR 3 INCH THERMAL PRINTER REMOVE/ INSTALL  Page: A-5 POS-3520 USER S MANUAL...
  • Page 79 Appendix A System Assembly  Page: A-6 POS-3520 USER S MANUAL...
  • Page 80 Appendix A System Assembly  Page: A-7 POS-3520 USER S MANUAL...

  • Page 81: Exploded Diagram For Msr & Fingerprint Module Remove

    Appendix A System Assembly EXPLODED DIAGRAM FOR MSR & FINGERPRINT MODULE REMOVE/ INSTALL  Page: A-8 POS-3520 USER S MANUAL...

  • Page 82: Exploded Diagram For Fingerprint Module

    Appendix A System Assembly EXPLODED DIAGRAM FOR FINGERPRINT MODULE  Page: A-9 POS-3520 USER S MANUAL...

  • Page 83: Exploded Diagram For Pos-3520 Hard Disk Drive Remove/Install

    Appendix A System Assembly EXPLODED DIAGRAM FOR POS-3520 HARD DISK DRIVE REMOVE/ INSTALL  Page: A-10 POS-3520 USER S MANUAL...
  • Page 84 Appendix A System Assembly  Page: A-11 POS-3520 USER S MANUAL...
  • Page 85 Appendix A System Assembly  Page: A-12 POS-3520 USER S MANUAL...

  • Page 86: Exploded Diagram For Pos-3520 Lcd Panel Remove/ Install

    Appendix A System Assembly EXPLODED DIAGRAM FOR POS-3520 LCD PANEL REMOVE/ INSTALL  Page: A-13 POS-3520 USER S MANUAL...
  • Page 87 Appendix A System Assembly  Page: A-14 POS-3520 USER S MANUAL...

  • Page 88: Exploded Diagram For Pos-3520 Mini-Pcie Installation

    Appendix A System Assembly EXPLODED DIAGRAM FOR POS-3520 MINI-PCIE INSTALLATION  Page: A-15 POS-3520 USER S MANUAL...

  • Page 89: Exploded Diagram For Pos-3520 Motherboard

    Appendix A System Assembly EXPLODED DIAGRAM FOR POS-3520 MOTHERBOARD  Page: A-16 POS-3520 USER S MANUAL...
  • Page 90 Appendix A System Assembly  Page: A-17 POS-3520 USER S MANUAL...

  • Page 91: Exploded Diagram For Pos-3520 Msr Module

    Appendix A System Assembly EXPLODED DIAGRAM FOR POS-3520 MSR MODULE  Page: A-18 POS-3520 USER S MANUAL...
  • Page 92 Appendix A System Assembly  Page: A-19 POS-3520 USER S MANUAL...

  • Page 93: Exploded Diagram For Pos-3520 Msr & Lcd Assembly

    Appendix A System Assembly EXPLODED DIAGRAM FOR POS-3520 MSR & LCD ASSEMBLY  Page: A-20 POS-3520 USER S MANUAL...

  • Page 94: Exploded Diagram For Pos-3520 Printer Assembly

    Appendix A System Assembly EXPLODED DIAGRAM FOR POS-3520 PRINTER ASSEMBLY  Page: A-21 POS-3520 USER S MANUAL...
  • Page 95 Appendix A System Assembly  Page: A-22 POS-3520 USER S MANUAL...

  • Page 96: Exploded Diagram For Pos-3520 Top Cover Assembly

    Appendix A System Assembly EXPLODED DIAGRAM FOR POS-3520 TOP COVER ASSEMBLY  Page: A-23 POS-3520 USER S MANUAL...
  • Page 97 Appendix A System Assembly EXPLODED DIAGRAM FOR VFD MODULE ASSEMBLY  Page: A-24 POS-3520 USER S MANUAL...
  • Page 98 APPENDIX TECHNICAL SUMMARY This section will give you a brief introduction of the allocation maps for the system resources. Sections included: Block Diagram Interrupt Map DMA Channels Map I / O Map Watchdog Timer Configuration Flash BIOS Update Page: B-1...

  • Page 99: Block Diagram

    Appendix B Technical Summary BLOCK DIAGRAM Page: B-2 ′ POS-3520 USER S MANUAL...

  • Page 100: Interrupt Map

    Intel(R) ICH8 Family PCI Express Root Port 1 - 283F Intel(R) ICH8 Family PCI Express Root Port 6 - 2849 Intel(R) ICH8 Family USB Universal Host Controller - 2830 Intel(R) ICH8 Family USB2 Enhanced Host Controller - 2836 ′ Page: B-3 POS-3520 USER S MANUAL...

  • Page 101: Dma Channels Map

    Appendix B Technical Summary DMA CHANNELS MAP DMA Channel Assignment Direct memory access controller Page: B-4 ′ POS-3520 USER S MANUAL...

  • Page 102: I/O Map

    0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A2-0x000000BF Motherboard resources 0x000000C0-0x000000DF Direct memory access controller 0x000000E0-0x000000EF Motherboard resources 0x000000F0-0x000000FF Numeric data processor 0x000001F0-0x000001F7 Primary IDE Channel 0x00000274-0x00000277 ISAPNP Read Data Port 0x00000279-0x00000279 ISAPNP Read Data Port ′ Page: B-5 POS-3520 USER S MANUAL...
  • Page 103 Intel(R) ICH8M 3 port Serial ATA Storage Controller - 0x0000D800-0x0000D807 2828 Intel(R) ICH8M 3 port Serial ATA Storage Controller - 0x0000D880-0x0000D883 2828 Intel(R) ICH8M 3 port Serial ATA Storage Controller - 0x0000DC00-0x0000DC07 2828 Page: B-6 ′ POS-3520 USER S MANUAL...
  • Page 104 Appendix B Technical Summary I/O MAP ASSIGNMENT 0x0000E000-0x0000EFFF Intel(R) ICH8 Family PCI Express Root Port 6 - 2849 0x0000E800-0x0000E8FF Realtek PCIe GBE Family Controller 0x0000FFA0-0x0000FFAF Intel(R) ICH8M Ultra ATA Storage Controllers - 2850 ′ Page: B-7 POS-3520 USER S MANUAL...

  • Page 105: Watchdog Timer Configuration

    (3) Exit the extended function mode To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once SuperIO exits the Extended Function Mode, it goes back to the normal running mode. Page: B-8 ′ POS-3520 USER S MANUAL...
  • Page 106 ;------ Logic device activation for watch dog timer ------------------------------------------ 030h ;------ Set second as counting unit ------------------------------------------------------------- 0F5h not 08h ;------ Set timeout interval as 30seconds and start counting -------------------------------- 0F6h ;------ Exit the extended function mode ------------------------------------------------------- 0AAh ′ Page: B-9 POS-3520 USER S MANUAL...

  • Page 107: Flash Bios Update

    (4) Select [Boot] menu. (5) Select [Boot Devices Priority] sub-menu, set the USB bootable device to be the 1st boot device. (6) Pressing <F10> key to save configuration and exit the BIOS setup menu. Page: B-10 ′ POS-3520 USER S MANUAL...
  • Page 108 User can type “AFUDOS/?” to see all the definition of each control options. The recommend option for BIOS ROM update include following parameters: Program main BIOS image. /B: Program Boot Block. /N: Program NVRAM. /C: Destroy CMOS checksum /X: Don’t check ROM ID. ′ Page: B-11 POS-3520 USER S MANUAL...
  • Page 109 After BIOS update procedures complete, the messages should be like the figure shown below. User can restart the system and boot up with new BIOS now. Page: B-12 ′ POS-3520 USER S MANUAL...
