QUANTUM™ LX EVAPORATOR REPLACEMENT PARTS (Page 1 of 2)
Frick Number SAP Number
639A0206H05 484047
639A0185H10
639A0185H30
639A0261H01
639B0117H01
639C0132H01
639C0143H01
640A0032H02
639A0278H01
639B0104H01
649A1112Gxx
649A1063G99
639D0218H01
639D0191H02
640D0186H01
639B0115H02
639C0141G01 686440
639B0116H01
QUANTUM LX EVAPORATOR CONTROL PANEL
™
Evaporator Q5 Operator Interface Panel
Description
Circuit Breakers
5 Amp circuit breaker
Control Power
483963 2-Pos. Selector Switch (Control Power)
483966 Latch, 3 Across (Attaches contact block to switch mechanism)
Display
484329 CCFT inverter
670741 Display Harness
484379 Display
670593 Mounting plate (for Display, CPU and Interface board)
569676 Plexiglas Fill-piece for display
548266 Display adapter board (Bat wing)
552141 Inverter cable
Flash Cards and Software
901354 Program Flash Card (the xx indicates program version)
485995 Quantum™ LX Setpoint Saver (USB Drive)
Harnesses
850941 DC power and communications harness
696514 Keypad and Communications cable kit
Keypads
484621 Keypad/overlay with Frick
Power Supplies
642308 12 VDC power supply
Quantum™ Controllers
Q5 Board (Advantage)
677556 Q5 Interface Communications Board
MAINTENANCE
® logo (Quantum™ LX)
