3.1.6 Headset in HOLD Mode, OFF Charger, Mic Boom UP

The response to stimuli of the headset while in HOLD mode is outlined below:
Remote Dialcard Action
ANY KEY
Headset Action
MIC BOOM TO DOWN
POSITION
FLASH KEY
VOLUME UP/DOWN
Base Action
INTERCOM
ALL OTHER KEYS
3.1.7 Headset in INTERCOM Mode (Mic Boom must be Down & Base Corded must be
Lifted)
INTERCOM mode is entered by pressing the INTERCOM key on the headset to page the base;
if the base answers the page, then INTERCOM mode is enabled. INTERCOM mode can be
entered while in the IDLE or HOLD state.
The response to stimuli of the headset while in INTERCOM mode is outlined below:
Remote Dialcard Action
PHONE KEY
OFF KEY
HOLD KEY
INTERCOM
MEM
REDIAL
VOLUME UP/DOWN
# KEYS
Headset Action
MIC BOOM TO UP POSITION
FLASH KEY
VOLUME UP/DOWN
Reference: PRC 00B6
This document is proprietary to V
Specifications are preliminary and are subject to change without notice.
V E
TECH NGINEERING
Product Specification
VTH1930 (Wireless Headset Phone)
NO ACTION
HEADSET OFF-HOOK, CANCEL HOLD CONDITION
NO ACTION (No Keybeep)
INCREMENT/DECREMENT VOLUME SETTING
Response
PAGING TO HEADSET
NO RELATED HEADSET ACTION
PHONE MODE
EXIT INTERCOM & RETURN TO PREVIOUS MODE
NO ACTION (No Keybeep)
NO ACTION (No Keybeep)
NO ACTION (No Keybeep)
NO ACTION (No Keybeep)
INCREMENT/DECREMENT VOLUME SETTING
NO ACTION (No Keybeep)
EXIT INTERCOM & ENTER IDLE MODE
NO ACTION (No Keybeep)
INCREMENT/DECREMENT VOLUME SETTING
