TITLE
MODEL
3

Operating Modes

The following section will outline in detail the operation of the product in particular modes in
accordance to various stimuli. Some sections will describe the operation of various elements in
response to different operating modes.
3.1
Headset & Remote Dialcard Unit
The headset and the Remote dialcard operation will be grouped together since the remote
dialcard is simply and Infrared extension of the headset.
3.1.1

Headset Phone Mode (OFF-HOOK)

The headset can enter PHONE mode (OFF-HOOK) in the following manner :
-
Moving the mic boom switch to the extended or down position will always activate PHONE
mode.
-
With the mic boom in the down position, and the unit in an ON-HOOK state, pressing the
PHONE key on the dialcard will always activate PHONE mode.
-
When incoming ringing is present, pressing any key on the headset or dialcard with the
exception of the volume up/down keys will activate PHONE mode.
The response to stimuli while in PHONE mode is outlined below:
Remote Dialcard Action
OFF KEY
PHONE KEY
HOLD KEY
INTERCOM
MEM
REDIAL
VOLUME UP/DOWN
# KEYS
Headset Action
MIC BOOM TO UP POSITION
FLASH KEY
VOLUME UP/DOWN
Reference: PRC 00B6
This document is proprietary to V
Specifications are preliminary and are subject to change without notice.
V
E
TECH
NGINEERING
Product Specification
VTH1930 (Wireless Headset Phone)
ON-HOOK
FLASH LINE
ON-HOLD
NO ACTION (no Keybeep)
ACCEPT MEM LOCATION
DIAL OUT CONTENTS OF REDIAL BUFFER
INCREMENT/DECREMENT VOLUME SETTING (no keybeep)
DIAL OUT CORRESPONDING DTMF OR PULSE DIGITS
(except * key activates temporary tone in pulse mode)
ON-HOOK
FLASH LINE
INCREMENT/DECREMENT VOLUME SETTING (no keybeep)
E
C
TECH
NGINEERING
ANADA
C
ANADA
Response
Response
Revision: 0
L
.
TD
L
.
TD
Page: 15 of 31
21146
