2.3.4 MESSAGE WAITING LED

This LED will flash whenever the base has received a VMWI signal from the C.O.. It
will remain in this state until either the cancel VMWI signal is received from the C.O.
or the base unit power is removed..

2.3.5 INTERCOM LED

This LED will illuminate whenever INTERCOM mode is active.

2.3.6 HOLD LED

This LED will illuminate whenever a call is placed on hold; it does not matter whether
the hold condition was initiated from the headset or the base.

2.3.7 INTERCOM KEY

Pressing the INT.COM key will generate a base keybeep and send a paging signal
to the headset causing it to emit a distinctive ring. When in idle mode, the headset
will ring for a maximum of five times. To end the INTERCOM conversation, the
user presses INT.COM on the base or OFF on the handset. If the handset is in
PHONE mode when the base pages it, the handset will generate a long, soft non-
intrusive ringing tone.
2.3.8 0 ->9 Numeric Keys
In DTMF mode, pressing these keys will result in the appropriate DTMF tone being
sent out over the line. If the key is held then the tone is continuously sent.
In PULSE mode, pressing these keys will result in the appropriate pulse pattern
being sent out over the line. A beep is heard from the base.

2.3.9 */TONE key

When the TONE/PULSE switch on the base is in the PULSE position, pushing this
key will change the outgoing numbers from PULSE to DTMF for the duration of the
call. In TONE mode, this sends out the DTMF tone for *.

2.3.10 # key

In DTMF mode, pressing this key sends out an appropriate DTMF tone for #. In
PULSE mode, this key is inactive.

2.3.11 MEM KEY

This key is used for recalling phone numbers stored in speed dial memory.
To dial a number stored in speed dial memory:
1.) Press SPEAKERPHONE to get a dial tone.
2.) Press MEM and the number key (00..20).
The number stored is dialed out - e.g. 555-1234.
Location 00 is shared with the QUICKMEM key and can be accessed by pressing
the QUICKMEM key or by entering speed dial location 00. MEM dialing numbers
can only be programmed from the handset.
