- Page 1 Certification Exhibit FCC ID: U4A-SCYICLS2 IC: 6982A-SCYICLS2 FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0071.W06.11.A Manufacturer: Assa Abloy, Inc. Model: P1-IM/IKM Manual 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598...
- Page 2 PASSPORT 1000 Mortise Lock Installation Instructions A8032D 12/10 Copyright 2010, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
-
Page 3: Table Of Contents
Table of Contents Warning ...................2 General Description ..............3 Hardware Specifications ............3 Electronic Specifications ............3 Installation Wiring Overview ...........3 Installation Wiring ..............4 Parts Breakdown ..............7 Installation Instructions ............7 Operational Check ..............17 Warning Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 4: General Description
Passport 1000 Series P1 PoE Mortise Lock General Description The SARGENT Passport Series v.P1 cylindrical lock is available with either an HID® Prox 125 kHz or 13.56 MHz iCLASS® technology reader. It utilizes existing infrastructure and IEEE 802.3af PoE (Power over Ethernet) providing access control with Magnetic swipe and optional Proximity Reader and/or Keypad, as well as detailed audit capabilities- technology as a proven alternative to traditional access control installations. -
Page 5: Installation Wiring
Passport 1000 Series P1 PoE Mortise Lock Installation Wiring A. PoE Frame harness assembly C. PoE Door harness* (From McKinney) D. Passport 1000 Online P1 PoE Lock B. PoE data hinge (Patent Pending) (From McKinney) * Order of installation may vary. Refer to appropriate sections for instructions. - Page 6 Passport 1000 Series P1 PoE Mortise Lock Installation Wiring (Continued) Frame Harness Installation Components and wire harness supplied by McKinney: Suggested installation. Supplied by CI Cut end / ceiling-side PoE harness: B-Splice Crimp Connector TIA/EIB-568-B Standard Wiring Pair Number Wire White/Blue White/Blue Blue...
- Page 7 Passport 1000 Series P1 PoE Mortise Lock PoE Data Hinge Order of installation may vary. Refer to appropriate sections for instructions. Hinge-side harness connectors: • 4-pin male Molex connector • 6-pin male Molex connector with ground wire Lock-side harness connectors: •...
-
Page 8: Parts Breakdown
Passport 1000 Series P1 PoE Mortise Lock Parts Breakdown P1 PoE Lock with Magnetic Card Swipe With or Without Keypad Inside Inside Inside Outside Outside Outside ITEM No. PART No. DESCRIPTION 52-0757 Lens (Cliplite) 52-0738 Outside Passport Escutcheon Only (Magnetic Swipe and Keypad) 52-0739 Outside Passport Escutcheon Only (Magnetic Swipe) 52-0760... - Page 9 Passport 1000 Series P1 PoE Mortise Lock Parts Breakdown (Continued) P1 PoE Lock with Magnetic Card Swipe , 125 kHz Prox and Keypad Inside Inside Outside Outside ITEM No. PART No. DESCRIPTION 52-1103 Outside Passport Escutcheon only (Magnetic Swipe, Keypad and Proximity Reader) 52-3593 Slim Style Keypad Assembly 01-9299...
- Page 10 Passport 1000 Series P1 PoE Mortise Lock Parts Breakdown Magnetic Card Swipe With 13.56 MHz iCLASS and Keypad ITEM No. PART No. DESCRIPTION 52-4402 Outside Mask Assembly 52-1255 Outside Escutcheon - iCLASS 52-3593 Slim Style Keypad Assembly 01-9299 #4-40 x 3/16” Machine Screw 52-4243 Swipe Reader Assembly 52-4401...
- Page 11 Passport 1000 Series P1 PoE Mortise Lock 8200 Series Mortise Lock ITEM PART No. DESCRIPTION See catalog #41 Cylinder (1-1/8” Minimum Length) 13-0140 Cylinder Compression Spring See catalog 1KB-1 Cylinder Rosette See catalog Mortise Lockbody 77-2592 130 KB Thumbturn for Deadbolt Functions Only See catalog Inside Lever Handle See catalog...
-
Page 12: Installation Instructions
Passport 1000 Series P1 PoE Mortise Lock Installation Instructions Door Preparation A. Verify Hand and Bevel of Door Left Hand Left Hand Right Hand Right Hand Hinges Left. Reverse Bevel Hinges Right. Reverse Bevel Open Inward. Hinges Left. Open Inward. Hinges Right. - Page 13 Passport 1000 Series P1 PoE Mortise Lock Connector 2 How to Change Hand of Lockbody Ring Terminal A. Reverse Lock Hand Red surface of locking piece must face the outside/ locked side of door. To rotate locking piece (Fig. 2A): 1.
- Page 14 Passport 1000 Series P1 PoE Mortise Lock 3 Install Lock Body 1. Feed the wires first through the mortise pocket and out the inside prep, followed by the lockbody (Fig. 3A). 2. The wires from the lockbody exit the inside door prep through the mortise pocket (Fig.
- Page 15 Passport 1000 Series P1 PoE Mortise Lock 5 Install Inside and Outside Levers 1. Slide the outside lever and spindle assembly through the door and lockbody. 2. Using the inside adapter plate and spindle, secure loosely with (2) #8-32 screws. Note: Position threaded hole on the inside adapter to align with lever hole.
- Page 16 Passport 1000 Series P1 PoE Mortise Lock 7 Install Gasket (Optional) Note: Optional, for non-fire rated doors only. For non-fire rated door applications, an optional gasket may be used as a weather seal between the escutcheon and the outside Gasket door surface.
- Page 17 Passport 1000 Series P1 PoE Mortise Lock 9 Install Inside Module Component Assembly Insert bottom of Module Component Assembly first (Fig. 9A), then clip top of Assembly to backplate, verifying both tabs attached securely. Tabs Outside of Door Fig. 9A 10 Attach Connectors Secure the following connectors onto the circuit board (Fig.
- Page 18 Passport 1000 Series P1 PoE Mortise Lock 11 Install Inside Escutcheon 1. Position inside escutcheon as shown (Fig. 11A). Verify that all wires are positioned within the (2) #8-32 x 1/2” escutcheon Torx Screws to avoid pinching. 2. Attach escutcheon with (2) #8-32 x 1/2” T-20 Torx pan head screws.
-
Page 19: Operational Check
Passport 1000 Series P1 PoE Mortise Lock Operational Check IMPORTANT: Be sure to test functions prior to closing door. In all cases, perform the following checks: 1. Ensure that inside lever retracts latch (and deadbolt for dead- bolt functions). • For units with cylinders, the following checks apply: Insert key into cylinder and rotate: a. - Page 20 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2010, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
