Installation Instructions
Installation Instructions
DL Series
Tubular Lock
1
Tools Required
• #2 Phillips screwdriver
• T20 sized security bit
2
Package Contents
1
WARNING
This product can expose you to lead
which is known to the state of California
to cause cancer and birth defects or other
reproductive harm. For more information go
to www.P65warnings.ca.gov.
1-800-727-5477 • www.sargentlock.com
Copyright © 2008, 2009, 2012, 2016, 2020, SARGENT Manufacturing Company. All rights reserved. Reproduction in
whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
• 1/8" drill bit
• 2-1/8" drill bit
3
2
4
6
Figure 1
Part No.
1
—
2
82-1038
DL-2053*
DL-2054*
DL-2055*
DL-2056*
DL-2057*
DL-2058*
3
DL-2059*
DL-2060*
DL-2061*
DL-2113*
DL-2114*
DL-2115*
4
82-0017
• 1" drill bit
12
8
5
7
9
10
Description
Qty
Lever
2
Set Screw
2
Rose Assembly -- CO Design
2
(15 Function)
Rose Assembly--CO Design
2
(65 Function)
Rose Assembly -- TO Design
2
(15 Function)
Rose Assembly -- TO Design
2
(65 Function)
Rose Assembly -- O Design
2
(15 Function)
Rose Assembly -- O Design
2
(65 Function)
Rose Assembly -- LN Design
—
(93 & 94 Functions Only)
Rose Assembly -- CR Design
—
(93 & 94 Functions Only)
Rose Assembly -- TR Design
—
(94 & 94 Functions Only)
Rose Assembly -- E2 Design
2
(15 Function)
Rose Assembly -- E2 Design
2
(65 Function)
Rose Assembly -- E2 Design
2
(93 & 94 Functions Only)
Mounting Post
2
* Specify Finish
11
Figure 1
Part No.
Description
DL-2005
Spring Housing
Mounting Plate
DL-0091
(93 & 94 Functions Only)
5
Mounting Assembly/Blank Rose (15-3
DL-2006*
Function)
Thru-bolt Plate Assembly
82-4022*
(TB-93 Function)
6
82-0347
Lever Springs
Latch -- 2-3/4" Backset
DL-5007*
(15 Function)
Latch -- 2-3/4" Backset
DL-5008*
(65 Function)
7
Latch-- 2-3/8" Backset
DL-5009*
(15 Function)
Latch -- 2-3/8" Backset
DL-5010*
(65 Function)
08-3788*
T-Strike Screw Pack
8
08-2853
28- Prefix Screw Pack (not shown)
800*
Standard T-Strike
808*
28- Prefix ANSI Strike (not shown)
9
13- or 14- Prefix Full Lip Strike (not
505*
shown)
10
AM-0044
Wrought Box Strike
11
DL-0023*
Push Button (65 Function Only)
12
DL-2020
Mounting Post Screw Pack
Qty
2
—
—
—
2
1
1
1
1
1
1
1
1
1
1
1
1
A7858F 10/20
