The explanation of Figure 1:
Number Component
1 PCIe X4
2 CSI Ports, DSI Ports
3 eDP Port
4 LVDS Port
5 HDMI (Type A)
6 SD Card Slot 2
7 SD Card Slot 1
8 Recovery Button
9 Reset Button
10 Power Button
11 Gigabit Ethernet Port
12 Headset Jack
13 Microphone Jack
14 Recovery / Bootstrap USB (Micro B)
15
USB 3 Port 1
16 USB 3 Port 2+3
General Purpose ‚Pins
17
18 General Purpose Pins
19 General Purpose Button
20 Debug UART via USB (Micro B)
21 DC power jack (12 V)
22 SATA Power
23 Configuration Pin Autostart
24 SATA
25 Fan Connector
26 JTAG
Connector
X10
X22
X15
X14
X13
X8
X9
S5
S4
S3
X16
X11
X12
X19
X21
X20
X24
X23
S2
X25
X1
X18
S1
X17
X26
X27
/Overview of the Eval Carrier
