Avionic Design Meerkat K1 Eval Kit User Manual page 15

Connector Component
X16 Ethernet RJ45
Connector Component
Standard SATA
X17
(Molex: 47306-5005)
Connector Component
SATA power
X18 (Tyco Electronics:
770997-1)
Pinout
Pin 1: ETH_D1_P
Pin 2: ETH_D1_N
Pin 3: ETH_D2_P
Pin 4: ETH_D3_P
Pin 5: ETH_D3_N
Pin 6: ETH_D1_N
Pin 7: ETH_D4_P
Pin 8: ETH_D3_N
Pinout
Pin 1: GND
Pin 2: A+
Pin 3: A-
Pin 4: GND
Pin 5: B-
Pin 6: B+
Pin 7: GND
Pinout
Pin 1: Vcc (8-17V)
Pin 2: GND
Pin 3: GND
Pin 4: +5 V
/Overview of the Eval Carrier
15
