Avionic Design Meerkat K1 Eval Kit User Manual page 18

Connector Component
eDP Output
X15 (TE Connectivity:
5-2069716-2)
Pinout Pinout
Pin 1: N.C. Pin 2: GND
Pin 3: EDP_LANE1_N Pin 4: EDP_LANE1_P
Pin 5: GND Pin 6: EDP_LANE0_N
Pin 7: EDP_LANE0_P Pin 8: GND
Pin 9: EDP_AUX_P Pin 10: EDP_AUX_N
Pin 11: GND Pin 12: +3V3_eDP
Pin 13: +3V3_eDP Pin 14: N.C.
Pin 15: GND Pin 16: GND
Pin 17: EDP_HPD_3V3 Pin 18: GND
Pin 19: GND Pin 20: GND
Pin 21: GND Pin 22: EDP_BL_EN
Pin 23. EDP_BL_PWM Pin 24: N.C.
Pin 25: N.C. Pin 26: +12V_EXT_BL
Pin 27: +12V_EXT_BL Pin 28: +12V_EXT_BL
Pin 29: +12V_EXT_BL Pin 30: N.C.
Pin M1: GND Pin M2: GND
Pin M3: GND Pin M4: GND
18
/Overview of the Eval Carrier
