Avionic Design Meerkat K1 Eval Kit User Manual page 17

Connector Component
LVDS Output
X14
(IPEX 20455-040E)
Pinout Pinout
Pin 1: N.C. Pin 2: +3V3_eDP_LVDS
Pin 3: +3V3_eDP_LVDS Pin 4: +3V3_EXT
Pin 5: N.C. Pin 6: GEN2_I2C_SCL
Pin 7: GEN2_I2C_SDA Pin 8: LVDS0_N
Pin 9: LVDS0_P Pin 10: GND
Pin 11: LVDS1_N Pin 12: LVDS1_P
Pin 13: GND Pin 14: LVDS2_N
Pin 15: LVDS2_P Pin 16: GND
Pin 17: LVDS_CLK_N Pin 18: LVDS_CLK_P
Pin 19: GND Pin 20: LVDS3_N
Pin 21: LVDS3_P Pin 22: GND
Pin 23: N.C. Pin 24: N.C.
Pin 25: GND Pin 26: N.C.
Pin 27: N.C. Pin 28: GND
Pin 29: N.C. Pin 30: N.C.
Pin 31: GND Pin 32: GND
Pin 33: GND Pin 34: N.C.
Pin 35: LVDS_PWM Pin 36: LVDS_BL_EN
Pin 37: N.C. Pin 38: +12V_EXT_BL
Pin 39: +12V_EXT_BL Pin 40: +12V_EXT_BL
Pin M1: GND Pin M2: GND
Pin M3: GND Pin M4: GND
17
/Overview of the Eval Carrier
