3.4 Pinouts of the connectors on the Eval Carrier

In this chapter you will find a list of the pinouts of the connectors of the Meerkat K1 Evaluation Carrier Board.
Connector Component
PCI Express
(Molex Card Edge
X10
Connector:
87715-9106)
Pinout Pinout
Pin A1: GND Pin B1: +12V_EXT
Pin A2: +12V_EXT Pin B2: +12V_EXT
Pin A3: +12V_EXT Pin B3: N.C.
Pin A4: GND Pin B4: GND
Pin A5: N.C. Pin B5: GEN2_I2C_SCL
Pin A6: N.C. Pin B6: GEN2_I2C_SDA
Pin A7: N.C. Pin B7: GND
Pin A8: N.C. Pin B8: +3,3V_EXT
Pin A9: +3,3V_EXT Pin B9: PCIE_TRST
Pin A10: +3,3V_EXT Pin B10: +3,3V_EXT
Pin A11: PEX_L0_NRST Pin B11: PEX_NWake
Pin A12: GND Pin B12: PEX_L0_NCLKREQ
Pin A13: PEX1_CLK_P Pin B13: GND
Pin A14: PEX1_CLK_N Pin B14: L1_TX_P
Pin A15: GND Pin B15: L1_TX_N
Pin A16: L1_RX_P Pin B16: GND
Pin A17: L1_RX_N Pin B17: NPRSNT2
Pin A18: GND Pin B18: GND
Pin A19: N.C. Pin B19: L2_TX_P
Pin A20: GND Pin B20: L2_TX_N
Pin A21: L2_RX_P Pin B21: GND
Pin A22: L2_RX_N Pin B22: GND
Pin A23: GND Pin B23: L3_TX_P
Pin A24: GND Pin B24: L3_TX_N
Pin A25: L3_RX_P Pin B25: GND
Pin A26: L3_RX_N Pin B26: GND
Pin A27: GND Pin B27: L4_TX_P
Pin A28: GND Pin B28: L4_TX_N
Pin A29: L4_RX_P Pin B29: GND
Pin A30: L4_RX_N Pin B30: N.C.
Pin A31: GND Pin B31: NPRSNT2
Pin A32: N.C. Pin B32: GND
