Avionic Design Meerkat K1 Eval Kit User Manual page 12

Connector Component
X1 Power Jack (8-17V Input)
Connector Component
Headphone Out
X11
(3,5mm Audio Jack)
Connector Component
Microphone In
X12
(3,5mm Audio Jack)
Connector Component
Recovery / Bootstrap USB
X19
(Micro B USB)
Connector Component
DEBUG UART USB
X25
(Micro B USB)
Pinout
Pin 1: Power
Pin 2: GND
Pinout
Pin 1: GND
Pin 2: Plug Detect
Pin 3: N.C.
Pin 4: HP_Out_Right
Pin 5: HP_Out_Left
Pinout
Pin 1: GND
Pin 2: N.C.
Pin 3: N.C.
Pin 4: Mic_In_Right
Pin 5: Mic_In_Left
Pinout
Pin 1: VBUS
Pin 2: D-
Pin 3: D+
Pin 4: ID
Pin 5: GND
Pinout
Pin 1: VBUS
Pin 2: D-
Pin 3: D+
Pin 4: ID
Pin 5: GND
/Overview of the Eval Carrier
12
