Avionic Design Meerkat K1 Eval Kit User Manual page 14

Connector Component
HDMI
X13
(Type A)
DSI_A_CLK_L_N
Pin 79:
Pin 80: GND
DSI_A_CLK_L_P
Pin 81: GND Pin 82: DSI_A_D0_N
Pin 83: GND Pin 84: DSI_A_D0_P
Pin 85: DSI_A_D1_L_N Pin 86: GND
Pin 87: DSI_A_D1_L_P Pin 88: GND
Pin 89: GND Pin 90: DSI_A_D2_N
Pin 91: GND Pin 92: DSI_A_D2_P
Pin 93: DSI_A_D3_L_N Pin 94: GND
Pin 95: DSI_A_D3_L_P Pin 96: GND
Pin 97: GND Pin 98: DSI_CSI_GPIO2
Pin 99: DSI_EN Pin 100: DSI_PWM
Pinout
Pin 1: TDMS D2+
Pin 2: TDMS D2 SHIELD
Pin 3: TDMS D2-
Pin 4: TDMS D1+
Pin 5: TDMS D1 SHIELD
Pin 6: TDMS D1-
Pin 7: TDMS D0+
Pin 8: TDMS D0 SHIELD
Pin 9: TDMS D0-
Pin 10: CLK+
Pin 11: CLK SHIELD
Pin 12: CLK-
Pin 13: CEC
Pin 14: HEC DATA-
Pin 15: I2C SCL
Pin 16: I2C SDA
Pin 17: HEC DATA-
Pin 18: +5 V
14
/Overview of the Eval Carrier
