Avionic Design Meerkat K1 Eval Kit User Manual page 16

Connector Component
JTAG Connector
X27
(FCI: 54202-T0810ALF)
Pinout
Pin 1: 1,8V EXT
Pin 2: 1,8V EXT
Pin 3: JTAG_NTRST_EXT
Pin 4: GND
Pin 5: JTAG_TDI
Pin 6: GND
Pin 7: JTAG_TMS
Pin 8: GND
Pin 9: JTAG_TCK
Pin 10: GND
Pin 11: JTAG_RTCK
Pin 12: GND
Pin 13: JTAG_TDO
Pin 14: GND
Pin 15: JTAG_NSRST
Pin 16: GND
Pin 17: JTAG_PD0
Pin 19: GND
Pin 20: JTAG_PD1
Pin 21: GND
/Overview of the Eval Carrier
16
