4.2 Turn on the Eval Kit

This chapter describes how to connect all the peripherals with the Eval Kit and how to turn on the Eval Kit.
1. Before you turn on the Eval Kit, connect all the peripherals with the Eval Kit
 1x HDMI cable (Type A)
 2x USB Cable Micro B for Debug and USB Recovery
 1x Ethernet cable
Optional items:
 1x computer with a terminal emulator
 1x keyboard with a USB Type A plug
 1x mouse with a USB Type A plug
 1x HD monitor with HDMI port (Type A)
2.1 Put the USB plugs of the mouse, keyboard the USB Ports. (see Figure 6):
2.2 Put one plug of the Ethernet cable to a network (with a DHCP server already set-up) and put the other
plug into the Ethernet Port of the Eval Kit.
