Avionic Design Meerkat K1 Eval Kit User Manual page 20

Connector Component
Extension Header II
X24
(2,54mm Pin Header)
Pinout Pinout
Pin 1: +1V8_EXT Pin 2: +1V8_EXT
Pin 3: DAP4_SCLK Pin 4: GPIO_
Pin 5: DAP4_FS Pin 6: GPIO_
Pin 7: DAP4_DIN Pin 8: GPIO_
Pin 9: DAP4_DOUT Pin 10: GPIO_
Pin 11: DAP4_MCLK Pin 12: GPIO_
Pin 13: GND Pin 14: GPIO_
Pin 15: GPIO_PH6 Pin 16: GPIO_
Pin 17: GPIO_PJ0 Pin 18: GND
Pin 19: GPIO_PO3 Pin 20: GEN1_I2C_SDA
Pin 21: GPIO_PO4 Pin 22: GEN1_I2C_SCL
Pin 23. GND Pin 24: GND
Pin 25: UART3_RX Pin 26: UART2_RX
Pin 27: UART3_TX Pin 28: UART2_TX
Pin 29: UART3_nRTS Pin 30: UART2_nRTS
Pin 31: UART3_nCTS Pin 32: UART2_nCTS
Pin 33: GND Pin 34: GPIO_PH1
Pin 35: USB2_P Pin 36: SPDIF_OUT
Pin 37: USB2_N Pin 38: SPDIF_IN
Pin 39: +5_EXT Pin 40: USB_VBUS_EN2
20
/Overview of the Eval Carrier
