Avionic Design Meerkat K1 Eval Kit User Manual page 13

Connector Component
CSI and DSI Ports
X22 (Tyco Electronics:
5177983-4)
Pinout Pinout
Pin 1: +12V ext Pin 2: +12V ext
Pin 3: +12V ext Pin 4: +12V ext
Pin 5: GND Pin 6: GND
Pin 7: CSI E CLK N Pin 8: GND
Pin 9: CSI E CLK P Pin 10: GND
Pin 11: GND Pin 12: CSI E D0 N
Pin 13: GND Pin 14: CSI E D0 P
Pin 15: CAM1 PWDN Pin 16: GND
Pin 17: CAM1 MCLK Pin 18: DSI_CSI_GPIO0
Pin 19: GND Pin 20: DSI_CSI_GPIO1
Pin 21: CSI_A_CLK_N Pin 22: GND
Pin 23: CSI_A_CLK_P Pin 24: GND
Pin 25: GND Pin 26: CSI_A_D0_N
Pin 27: GND Pin 28: CSI_A_D0_P
Pin 29: CSI_A_D1_N Pin 30: GND
Pin 31: CSI_A_D1_P Pin 32: GND
Pin 33: GND Pin 34: CSI_B_D0_N
Pin 35: GND Pin 36: CSI_B_D0_N
Pin 37: CSI_B_D1_N Pin 38: GND
Pin 39: CSI_B_D1_P Pin 40: GND
Pin 41: GND Pin 42: FLASH_EN
Pin 43: CAM_I2C_SCL Pin 44: GEN2_I2C_SCL_3V3
Pin 45: CAM_I2C_SDA Pin 46: GEN2_I2C_SDA_3V3
Pin 47: CAM2_MCLK Pin 48: CAM_NRST
Pin 49: +1V8_EXT Pin 50: +1V8_EXT
Pin 51: +3V3_EXT Pin 52: +3V3_EXT
Pin 53: +3V3_EXT Pin 54: +3V3_EXT
Pin 55: CAM2_PWDN Pin 56: GND
Pin 57: GND Pin 58: DSI_B_CLK_N
Pin 59: GND Pin 60: DSI_B_CLK_P
Pin 61: DSI_B_D0_N Pin 62: GND
Pin 63: DSI_B_D0_P Pin 64: GND
Pin 65: GND Pin 66: DSI_B_D1_N
Pin 67: GND Pin 68: DSI_B_D1_P
Pin 69: DSI_B_D2_N Pin 70: GND
Pin 71: DSI_B_D2_P Pin 72: GND
Pin 73: GND Pin 74: DSI_B_D3_N
Pin 75: GND Pin 76: DSI_B_D3_P
Pin 77: Pin 78: GND
13
/Overview of the Eval Carrier
